Cipher Gun
Cipher Gun
Assembly
Chapter
2
WARNING
Be careful not to bend the catalyst and resin needles.
Flush Valve Assembly (5104-01-01)
(See Drawing Flush Valve Assembly (5104-01-01) for reference.)
1. Install the O-Ring (7301-13-008)* onto the Flush Valve Button (5104-25-1)
2. Install the O-Ring (7301-3-007) onto the Flush Seal Body (5104-23-1)
3. Install the Compression Spring (9203-2-3) into the Flush Valve Body (5104-24-1)
4. Push the Flush Valve Button (5104-25-1) through the Compression Spring (9203-
2-3) located in the Flush Valve Body (5104-24-1), and screw on and tighten the
Flush Seal Body (5104-23-1)
5. Install the Flush Valve Seal (5104-26-1) onto the Flush Valve Body (5104-24-1)
and thread through the Flush Valve Neck (5104-22-1)
6. Install the Flush Elbow Assembly (5104-02-01) onto the Flush Valve Neck (5104-
22-1)
7. Install the Flush Valve Split Seal (5104-21-1) onto the Flush Valve Body (5104-24-
1)
NOTE
* O-Ring (7301-13-008) EPR use with Acetone only
DO NOT USE GREASE WITH EPR O-RING
Gun Head Assembly (CPR-2001-01)
1. Place New O-Ring (O-S-012) on Catalyst Fitting (MAX-2019) and Resin Fitting
(MAX-2022). Install both fittings into gun, making sure they are on the correct
sides of the gun block
2. Install new Seal (02441-1) onto Plug (53110-1) then thread Plug into Gun Block
