Megaject mk v overview, Introduction – Magnum Venus Plastech Megaject MKIV Revision 1_6 User Manual
Page 3
Megaject MK V Issue 1_6
Page 3 of 41
Megaject Mk V Overview
Introduction
This manual covers the operating and maintenance instructions of your particular model and
also includes details of options that may not be present on your machine. This will be
indicated at the relevant points.
This chapter shows the main machine components.
Control
Cabinet
Pipe Umbilical
Injection
Head
Solvent
Pump
Main Guards
Solvent
earth strap
Resin Pumps
Emergency Stop
Resin recirc
hoses (Pick up
pipes not
shown)
