Magnum Venus Plastech Megaject MKIV Revision 1_6 User Manual
Page 11
Megaject MK V Issue 1_6
Page 11 of 41
16. Machine Pull ‘On’ Switch
Activates the machine. Deactivates in the event of either the emergency stop button
being pressed or if air supply falls below 1 bar.
OPTION: CATAL Catalyst Flow Monitor (see Appendices)
17. Analogue Flow Meter
Indicates level of catalyst flow in recirculation and injection modes
18. Green ‘ON’ LED
Indicates when the CATAL unit is operating. This will only occur when power
is supplied and the main pump is in motion.
19. Low\High Range Switch.
Adjusts scale resolution for differing catalyst flow rates.
20. Alarm Set Level
Adjusts the catalyst flow level at which an alarm will sound.
(on back of cabinet)
External power supply socket. (+/- 9V)
Remote LED large/small repeater socket (repeaters optional)
Whistle - not shown
Sounds when machine requires flushing (1 minute after end of injection). Operating solvent
flush button cancels whistle and resets timer.
