CB-6000-RGT Material Monitor Manual
Rev. 10/2012 Page | 36
Resin Calculations work sheet:
• Pounds per Stroke Calculation – check Data sheet or MSDS sheet for your actual
weight.
Resin weight per Unit (Pounds per gallon) – (insert your actual weight)
Gallons per stroke – x (from chart above)
Pounds per stroke –
To convert that to Strokes per pound – 1.00
ч ч ч ч (pounds per stroke)
= (strokes per pound)
Strokes per pound –
Pulses per stroke – x
Pulses per Pound – (round to the nearest Pulse per Pound)
Resin Total Scale Factor (pounds) –
Display Decimal Place
(1 = 0 or 10 = 0.0 or 100 = 0.00 decimal display)
Pulses per pound – ч ч ч ч
Scale Factor (ASCFAC) =
•••• Kilogram per Stroke Calculation – using Specific Gravity: (see material data sheet)
Cc per Stroke – (from the chart above)
Specific Gravity – x
Grams per Stroke – (grams per stroke)
To convert that to Strokes per gram – 1.00
ч ч ч ч (grams per stroke)
= (strokes per gram)
Multiply by 1000 to get Kilogram – (strokes per kilogram)
Strokes per kilogram –
Pulses per stroke – x
Pulses per Kilogram – (round to the nearest Pulse per Kilogram)
Resin Total Scale Factor (kilograms) –
Display Decimal place (1 = 0 or 10 = 0.0 or 100 = 0.00 decimal display)
Pulses per kilogram – ч ч ч ч
Scale Factor (ASCFAC) =
Resin Rate Values: Display Value (rdSP 1) 1 = seconds, 60 = minutes and 3600 = Hours
Input Value (r I n
P 1) = # of pulses per unit
Adjust the decimal place by multiplying the values by 1, 10 or 100, both values must be adjusted
by the same proportion.
Time units = (1 = seconds, 60 = minutes and 3600 = Hours)
Decimal place: x (1 = 0 or 10 = 0.0 or 100 = 0.00 decimal display)
Display Value (rdSP 1) =
