CB-6000-RGT Material Monitor Manual
Rev. 10/2012 Page | 31
RESIN TOTAL METER SETUP SHEET:
I – I
n
P Counter A Input Parameters
Display Description MVP Setting
A Cnt Operating Mode cnt
ArESEt Reset Action 2ErO
AdECPt Decimal Position 0.0
ASCFAC Scale Factor 1 Enter factor here
ASCALr Scale Multiplier 1
ACNtLd Count Load Factor 0
A P-UP Reset Power-Up YES
(All other parameters in I – I
n
P remain as set by the factory)
QUICK REFERENCE:
or
6 – SPt Setpoint (alarm) Parameters SP – 1 settings
Display Description MVP Setting
Lit – 1 Annunciators nor
Out – 1 Output Logic nor
SUP – 1 Power Up State off
Act – 1 Action tOUt
ASn – 1 Assigment A Cnt
SP – 1 Setpoint Value 100 Enter signal out value
tOUt – 1 Setpoint Time Out 2.00
AUtO – 1 Auto Reset Action 2ErOAE
rSd -1 Reset with Display yes
(All other parameters remain as set by the factory)
QUICK REFERENCE:
or
PAR
Pro
F1
6 -SPt PAR
F2
PAR
Pro
F1
1 - I
n
P PAR
F2
