VHPC-2000 Metering Pump Manual
Rev. 05/2012
Page | 32
MAGNUM VENUS PLASTECH
CORPORATE HEADQUARTERS and MANUFACTURING
11692 56
th
Court * Clearwater, FL 33760 * Tel 727-573-2955 * Fax 727-571-3636
TECHNOLOGY CENTER and MANUFACTURING
1862 Ives Ave. * Kent, WA 98032 * Tel 253-854-2660 * Fax 253-854-1666
MVP Plastech UK
Chilsworthy Beam, Gunnislake, Cornwall, PL18 9AT UK, * Tel: +44 (0) 1822 832621
Fax: +44 (0) 1822 833999
www.mvpind.com
Rev. 05/2012
Assemblies Covered in this Manual:
VHPC-2000
Metering Pump Assembly
VHPC-2000-RV
Metering Pump Assembly – Relief Valve
VHPC-2000-RV-INT
Metering Pump Assembly – Relief Valve - International
VHPC-2000-C-3J
Metering Pump Assembly – Check Valve
VHPC-2000-C-UPS
Metering Pump Assembly – Check Valve – Suction Feed
VHPC-2000-COOK
Metering Pump Assembly – Slave Arm version
