Page 27: Catalyst pump assy vhpc-2000-rv-int, Figure 1-1
VHPC-2000 Metering Pump Manual
Rev. 05/2012
Page | 27
ASSOCIATED PARTS AND ASSEMBLIES
DESCRIPTION
PART NO.
ITEM
PARTS LIST
QTY
REPAIR KITS
PART NO.
VHPC-2000-RK
REPAIR KIT
DESCRIPTION
1
4101-14-1
1
OUTLET BODY
2
4101-2-1
1
CYLINDER
3
4101-7-1
1
INLET BODY
4
4101-11-1
1
PACKING NUT
5
4101-9-1
1
CLEVIS
6
4101-10-1
1
PISTON ROD
7
4101-12-1
1
UPPER GUIDE
8
4101-13-01
1
ROD PACK SPA
11
4101-4-1
1
PISTON BODY
12
7304-2-1
1
PISTON SEAL
13
4101-5-1
1
PISTON GUIDE
14
4101-6-1
1
SEAL RETAINER
15
9202-1-1
1
SPHERICAL BEARING
17
O-S-014
2
O-RING
18
4101-3-1
1
PISTON ROD SPRING
19
9201-1-5
1
5/32" SS BALL
20
9201-1-14
1
7/16" SS BALL
21
4101-1-1
1
LOCK NUT
22
4101-7-01
1
INLET BODY ASSEMBLY
*
*
*
*
*
*
*
*
*
Catalyst Pump Assy VHPC-2000-RV-INT
40
CV-2000
1
CHECK VALVE ASSEMBLY
35
CV-2002
1
SPRING HOUSING
36
CV-2004
1
SPRING
37
CV-2003
1
PISTON
38
O-S-011A
1
O-RING
39
CV-2001
1
SEAT HOUSING
16
O-S-013
3
O-RING
*
10
4101-8-1
1
TUBE FITTING
29
4101-18-1
1
JAM NUT
25
PF-HN-02-03J-SS
1
OUTLET FITTING
24
RV-1021
1
ADAPTER
*
FIGURE 1-1
Offset intake and outlet ports
one flat on hex as shown in
figure 1-1
Note:
26
6701-24-EN
1
WARNING DECAL
