PAT-LS-24050 Series Fluid Section Manual

Rev. 01/2012

Page | 20

• Inlet Valve Disassembly –

Using a pair of Pliers squeeze the Ball Stop and remove it from the Inlet Valve.

Remove the Foot Valve Spring and Ball from the Inlet Valve.

• Outlet Body Disassembly –

10. Unscrew the Packing Nut from the Outlet Body.

11. Remove the two Piston Seal Assemblies from Outlet Body.

NOTE: Use care not to drop the hard chrome balls in the Inlet and Piston
Bodies as they will be damaged. Replace all parts provided in the repair kit.
Use only original MVP parts.

NOTE: Some versions of the fluid section have only one Rod Seal.

NOTE: The PAT-LS-24050-GL Fluid Section also has the Spacer (PAT-LS-
2023) and Glutton Seal (PAT-LS-2024) in the Outlet Body (PAT-LS-2001-GL)
see drawing.
