Magnum Venus Plastech PATRIOT 1-3_4 PAT-LS-24050 User Manual
Page 17
PAT-LS-24050 Series Fluid Section Manual
Rev. 01/2012
Page | 17
Fluid Section Removal:
1.
Remove Suction Hose, Resin Hose and Accumulator / Filter assembly from the
Fluid Section. Follow all safety precautions before performing any repairs or
maintenance.
2.
Using a 1/2” Wrench and the Hex Wrench set remove the Shoulder Bolt (F-SB-
06-20) Holding the Lower Arm of the Slave Drive to the Fluid Section.
3.
Use a 9/16” Wrench to unscrew the four Hex Bolts (F-HB-06C-24-GR8) holding
the Fluid Section to the Power Head. Use caution to prevent the Fluid Section
from dropping after the bolts are removed.
CAUTION: Remove all fluid pressure and air pressure before beginning
service.
NOTE: Flushing the pumping system with suitable cleaning agent will make
cleaning, repair and maintenance easier.
