The display indicates your entry as the next cue to be
activated. When you push GO – this cue will fade in.
DEFAULT CUE LIST
The TL-5024 is provided with a factory default cue list.
This is the condition which will be set if the ERASE
ALL or ERASE CUEING function is invoked from the
ERASE menu. The settings for the default cue list are
as follows:
Cues 1 - 12 are set to scenes 1 - 12 in scene bank 1.
Cues 13 - 24 are set to scenes 1 - 12 in scene bank 2.
Cues 25 - 36 are set to scenes 1 - 12 in scene bank 3.
This repeat continues until all 16 scene banks have
been used. This occurs at cue number 192. Cues
193 through 240 are set to scene bank 0, scene 0. In
other words they are not assigned.
CREATING A CUE LIST
1. Push ENTER ENTER to access the cueing
menu. The following Display will be shown.
The left side of the display shows the cue number
being assigned. The upper right shows the bank
number of the scene assigned to that cue. The lower
right shows the scene number (within the bank)
assigned to that cue.
2. Use the and buttons to select one of the
items (cue number, bank number, or the scene
number). The item will flash when selected.
3. Use the and buttons to change the value of
the selected item.
To review cue assignments: Select the cue number
and run it up and down. The bank/ scene assigned
will be displayed as you cycle through the cues.
4. To set the "fade in" and "fade out" times for the
cue: Push the button until the following
display appears:
The cue number is shown on the left side of the
display. The right side shows the fade in time in
seconds on the top and the fade out time in seconds
on the bottom.
5. Use the and buttons to select either FI or
FO. The item will flash when selected.
6. Use the and buttons to change the value of
the selected item. The unit will not accept a
fade time of 00.
CUE LIST PLAYBACK
1. The next cue to be activated is shown in the
lower right section of the LCD STATUS display.
Use the and buttons to change the next
cue selection.
2. Push the GO button. The next cue (selected in
the step above) will be activated.
The overall intensity of cues is controlled by the
CUE MASTER fader. Cues will not be visible if the
CUE MASTER fader is down.
Individual channel fader settings and scenes are
added into the cue in a "greatest of" manner. In
other words if the cue sets a channel at 50% and
the fader for that channel is at 100% then the
resulting intensity for that channel will be 100%.
ERASE FUNCTIONS
Erase functions are used to partially or fully reset
the TL-5024 to it's default (factory set) state. They
can be invoked separately or as a group. There are
four functions as follows:
1. ERASE CUEING: Returns the cue list to its
default set of banks, scenes, and fade times.
The current and next cue numbers are not altered.
2. ERASE CHASER: Returns the chase step
assignments to the default set of banks,
scenes and channel settings. The current
chase number will not be altered.
3. ERASE SCENES: All channels of all scenes in
all banks will be set to zero intensity. The
current bank number will not be altered.
4. ERASE SOFTPATCH: Patch page 1 will be
set to a 1 to 1 assignment and will become
the active page. Patch page 2 will be
completely cleared of all assignments.
CUE BK01
001 SC01
CUE FI02
001 FO02
