TL-5024 LIGHTING MEMORY CONSOLE
Version 0.93
OWNERS MANUAL
07/20/2012
STATUS DISPLAY
The diagram below shows what information is given on the status display during normal operation. When the
menu system is in use then other information will be shown.
CHANNEL ASSIGNMENTS (PATCHING)
You can assign dimmer channels to console channels
in other than a 1 to 1 correspondence. For instance
you may want to have the lights connected to dimmer
channels 1 and 2 assigned to console fader 3. (You
can have several dimmer channels patched to a single
console fader but you cannot assign a dimmer channel
to more than 1 console channel at a time.) This set of
channel assignments or “patch” information can be
saved in the console as a “patch page”.
PATCH PAGES
The TL-5024 contains 2 patch pages. In other words
you can have two complete sets of channel
assignments in the console and switch between them.
In situations where the console is used for different
applications, multiple patch pages can save time that
would be spent re-patching each channel for a given
application. The current patch page may be toggled
between the two pages by using the MENU system.
DEFAULT CHANNEL ASSIGNMENTS
The TL-5024 is provided with a default channel
assignment set for patch page 1. This assignment
results in a 1 to 1 patch for dimmer channels 1 - 24.
The pattern is repeated beginning at dimmer channel
25 (It is assigned to console channel 1 again). The
repeat continues up to dimmer channel 256.
The default for patch page 2 is all channel
assignments completely cleared.
TO CHANGE THE CURRENT PATCH PAGE
1. Push ENTER ENTER to access
the PATCH submenu. The following display will
appear with the page number (1 or 2) flashing.
2.
Use the button to change the number.
ASSIGNING CURRENT PATCH PAGE CHANNELS
Channel assignments are always applied only to the
currently selected patch page.
1. Push ENTER ENTER ENTER
to access the REPATCH submenu. The following
display will be shown.
The top row shows a dimmer channel number. The
bottom row shows the console channel (fader) to
which the dimmer channel number is assigned. Use
the and buttons to cycle through the dimmer
channel numbers. The assigned console channel
will be shown for each one. You can change the
console channel number with the and buttons.
You can assign more than one dimmer channel to
any console channel. A dimmer channel cannot be
assigned to multiple console channels. In other
words - any particular dimmer can be assigned to
only one console channel.
B01 Q000
C01 N001
Current Cue (0 - 240)
PAGE=1
REPATCH
Current Scene Bank (1 - 16)
Use to change
Current Chase Pattern (1 - 12)
Use to change
Next Cue (0 - 240)
Use and to change
DIM 001
CON 01
