UNLINKING ALL RECEIVERS
Hold the link control button down for about 5 seconds.
The indicator LED will go to a flash state for about 10
seconds then return to ON. The link indicator on the
receiver unit(s) will go OFF
.
Link release for a single receiver unit can only be
performed at the receiver unit.
MAINTENANCE AND REPAIR
TROUBLESHOOTING
Check that the multiplex cable is not defective.
To simplify troubleshooting, reset the unit to provide a
known set of conditions.
Make sure that the dimmer address switches are set to
the desired channels.
OWNER MAINTENANCE
The best way to prolong the life of your TL-5024 is to
keep it dry, clean, and covered when not in use.
The unit exterior may be cleaned using a soft cloth
dampened with a mild detergent/water mixture or a
mild spray-on type cleaner. DO NOT SPRAY ANY
LIQUID directly on the unit. DO NOT IMMERSE the
unit in any liquid or allow liquid to get into the controls.
DO NOT USE any solvent based or abrasive cleaners
on the unit.
The faders are not cleanable. If you use a cleaner in
them – it will remove the lubrication from the sliding
surfaces. Once this happens it is not possible to re-
lubricate them.
The white strips above the faders are not covered by
the TL-5024 warranty. If you mark on them with any
permanent ink, paint etc. it is likely that you will be
unable to remove the markings without damaging the
strips.
INTERNAL MAINTENANCE
There are no user serviceable parts in the unit.
Service by other than Lightronics authorized agents
will void your warranty.
EXTERNAL POWER SUPPLY INFORMATION
The TL-5024 may be powered by an external supply
with the following specifications:
Output Voltage: 13 to 25 Volts AC or DC
Output Current: 400 Milliamps
Connector: 2.1mm female connector
NOTE: If a DC Supply is used – the center pin must
be the NEGATIVE voltage.
OPERATING AND MAINTENANCE ASSISTANCE
Dealer and Lightronics Factory personnel can help
you with operation or maintenance problems.
Please read the applicable parts of this manual
before calling for assistance.
If service is required - contact your dealer or contact
the Lightronics Service Dept.
