Sponsler, Inc. SP718-V Modulated Carrier Amplifier pg 4 DOC#: MN-718V-A
5.60
1.40
3/4-14 FNPT
2.40 DP.
3.75 DIA.
5-5-97
TN
EM SP718-V-A
SP718-V REV. A AMPLIFIER
\ELECT\SP718V.DWG
NONE
DRAWING NUMBER
MATERIAL
SPONSLER, INC.
SCALE
DRAWN BY
DATE
APPR. BY
DATE
REVIEWED BY
DATE
DESCRIPTION
REV. #
FILE NAME
COD
REV CK DR AUTH REVISION RECORD DATE
SIGNAL IN +
SIGNAL IN –
ANALOG OUT +
ANALOG OUT –
110 VAC NEU (DC-)
110 VAC HOT (DC+) 1
2
3
4
5
6
TERMINAL LOCATION
NOTE: DIMIENSIONS ARE IN INCHES
.90
3.00 DIA.
POWER INDICATOR
F/S FREQUENCY RANGE SELECT
JU1 60-245 Hz
JU2 220-925 Hz
JU3 845-3800 Hz
ANALOG
OUTPUT
SELECT
NOTE:
Condulet enclosure not
available for 120 volts,
consult factory
©2009
Pub. No. MN-718V-A
(09/09)
