PRIN TO OF O
Red Lens
Printer Holster
* * * O R I G I N A L C O P Y * * *
message,
bottom of
ticket
OPERATION PROCEDURE
T675 WITH SP825 DATACUBE & SP834 PORTABLE PRINTER
To be performed as the final segment of delivery procedure.
1) Turn the SP825 ‘ON’ by depressing the P/B switch. Two short low volume
beeps will occur and the green LED
indicator flashes quickly.
2) With red lens inward, align SP825 in T675 bracket. One long loud volume
beep occurs when data is successfully transferred to SP825.
3) Within 1 ½ minutes with the red lens inward, insert SP825 into SP834
printer holster
P/B SWITCH
GREEN LED
