PROCEDURE FOR MAKING A PRESET DELIVERY
PROCEDURE FOR MAKING A PRESET DELIVERY
1. Turn the Selector Switch to the
STOP
position.
2. Press
the
SELECT
button. The display will show Prod #.
3. Press
INCREASE
to select the product desired for delivery.
4. Press
SELECT
when the correct Prod # is displayed. This will advance to
the preset display.
5. The left most digit in the display will be flashing. Press
INCREASE
to set
the value of the first digit. When the value is chosen, press
SELECT
. The
next digit to the right will flash. If the digit does not need to be changed,
press
SELECT
to move one digit to the right.
6. Press
INCREASE
to change the value of the second digit. When the value
is chosen, press
SELECT
.
7. Continue in this manner until all digit positions have been selected. After the
last digit is selected, the display will return to the first screen, which is the
Delivery Total
. Or, switch to
RUN
when the desired amount is shown.
8. Turn the Selector Switch to
RUN
. DO NOT OPEN THE HOSE NOZZLE.
When the display stops counting, turn the Selector Switch back to
STOP
.
This step is necessary to allow for hose stuffing. If less than 1 Gallon was
recorded, the display will reset to 0 and no ticket will be printed.
9. Turn the Selector Switch to
RUN
. The display will reset and the hose nozzle
should now be opened to start the delivery. When the preset has been
reached, the valve will close.
10. Turn the Selector Switch to the
position to print out a delivery ticket.
PROCEDURE FOR PRINTING A DIAGNOSTIC TICKET
PROCEDURE FOR PRINTING A DIAGNOSTIC TICKET
1. Put a blank ticket in the Epson Printer.
2. Turn the Selector Switch to
SHIFT PRINT
for less than 2 seconds.
3. Turn the Selector Switch back to
and a Diagnostic ticket will be
printed.
PROCEDURE FOR PRINTING A SHIFT TICKET
PROCEDURE FOR PRINTING A SHIFT TICKET
1. Put a blank ticket in the Epson Printer.
2. Turn the Selector Switch to
SHIFT PRINT
for more than 2 seconds.
SHIFT PRINT
SHIFT PRINT
Position
Position
SELECT
< Delivery Total
200
.
0
INCREASE
INCREASE
INCREASE
INCREASE
PROD 1
SELECT
PROD 2
PROD 4
PROD 3
L5432
.
0
< 10 Digit Total-
izer
SELECT
k98765
< k-Factor
SELECT
SELECT
SELECT
< Temperature
< Flow Rate
098
.
023
INCREASE
INCREASE
INCREASE
INCREASE
F 70
.
0
PROD 1
SELECT
PROD 2
PROD 4
PROD 3
27
.
2 F
< k-Factor
102
.
965
CALIBRATION
CALIBRATION
Position
Position
INCREASE
“If Delivery is
Active”
o
INCREASE
