Operating Button

ON: Press and Hold

OFF: Release

Multi Indication LED

• Auto-Calibration (Solid Bright Red Light)

• Ready To Use (Solid but Dimmer Red Light)

• Stud Edge (Blinking Red Light)

Stud Sensor

Battery Replacement:

Note: Only use the batteries specifi ed (1.5V, AG13, LR44, L1154, A76 or 157). Put positive and negative pole in the right place. Do

not throw away used batteries in the household garbage. Give them to the collections station or dispose of them at a special
garbage depot that accepts batteries. Remove depleted batteries from the product. Non-rechargeable batteries must not
be recharged. Do not use different types of batteries and do not mix new and used batteries. Do not short-circuit connector
clips (which you could do, for example, by touching the connector clips with something metallic). Do not mix alkaline,
standard (carbon-zinc), or rechargeable batteries.

Stud Finder Instructions

Cover

Specifi cations:

The operating temperature range is from 14°F to 122°F (-10°C to +50°C), with the best temperature being up to 77 F (25°C), humidity
below 60% and altitude up to 6,500 feet (2,000 meters). Do not use the Stud Finder in conditions that are not within these parameters
or it may not function correctly.

1. The detector must not be used in the presence of moisture such as dew or rain.
2. Do not operate the detector with the battery cover removed.

Step 1 – Remove Battery cover

Remove the back cover and the old batteries.

Step 2 – Battery Replacement

Replace the 2 button cell batteries with two 1.5V batteries, number AG13, LR44, L1154, A76 or 157.
When installing the batteries into the unit, place the positive (+) side of the battery away from the spring
inside the unit.

Step 3 – Replace Battery Cover

Replace the back cover.

www.levelmount.com

1-888-229-1459

EU: +0044 844 567 2657

UK: 0844 567 2657

Placa de Soporte

¿Qué hay en la caja?

Brazo Giratorio o Voladizo

Brazos de Extensión

Bolsa 7

(8) M5 Arandelas de presión

(8) M5 Tuercas

Tornillos Phillips

(8) M5X48 mm

Bolsa 5

(4) Separadores
Ø17,5 x Ø8,3 x 22,5 mm

(4) Arandelas

Ø20 x Ø5,5 1,0 mm

(4) Separadores
Ø12,5 x Ø5,5 x 16,5 mm

Bolsa 1

(4) M4 Arandelas
de presión

(4) M4X20 mm
Tornillos Phillips

(4) M4X30 mm
Tornillos Phillips

(4) M4X12 mm
Tornillos Phillips

Soporte TV con
respaldo plano

Bolsa 3

(4) M6 Arandelas
de presión

(4) M6X35 mm
Tornillos Phillips

(4) M6X24 mm
Tornillos Phillips

(4) M6X12 mm
Tornillos Phillips

Bolsa 4

(4) M8 Arandelas
de presión

(4) M8X40 mm
Tornillos Phillips

(4) M8X25 mm
Tornillos Phillips

Bolsa 2

(4) M5X20 mm
Tornillos Phillips

(4) M5X30 mm
Tornillos Phillips

(4) M5 Arandelas
de presión

(4) M5X12 mm
Tornillos Phillips

Soporte TV con
respaldo plano

Bolsa 6

(1) Llave Allen

(6) Tornillo hexagonal para madera
Ø6.3 x 75mm

(6) Tacos para hormigón Ø12 x 60mm

(6) Arandelas
28 mm x Ø8 mm x 1,5 mm

(4) M8X16 mm
Tornillos Phillips

Soporte TV con
respaldo plano

Soporte TV con
respaldo hueco

V l di

Llave de Tubo
