30DJ
TV Bracket
Wall Plate
What’s in the box? 30LP, 30T, 30SJ, 30DJ, RSMSL & RSMSS
(4) Mini Bayonet
(2) Concrete Anchors
Bag 1
(2) Hex Screw
Bag 2 Bag 3 Bag 4
Bag 5
(1) M4 x 8mm
Theft Deterrent
Screw
(4) Washer
16mm x 5.3mm x 1.2mm
(4) Spacer
14mm x 16mm,
(4) Washer
16mm x 6.3mm x 1.2mm
Bag 6
(8) Phillips
M5 Nut Screw
(8) Washer
16mm x 5.3mm x 1.2mm
(8) M5 x 12mm
Anti-Theft Bolt
(4) M6 x12mm Phillips Bolt
(4) M6 x 35mm Phillips Bolt
(4) M6 x 24mm Phillips Bolt
Recessed
Back
TV
Hardware
Flat Back
TV Hardware
(4) M6 Lock Washer
(4) M5 x12mm Phillips Bolt
(4) M5 Lock Washer
(4) M5 x 30mm Phillips Bolt
(4) M5 x 20mm Phillips Bolt
Recessed
Back
TV
Hardware
Flat Back
TV Hardware
(4) M4 x12mm Phillips Bolt
(4) M4 x 20mm Phillips Bolt Recessed
Back
TV
Hardware
Flat Back
TV Hardware
(4) M4 Lock Washer
Bag 7
(4) M4 x 30mm Phillips Bolt
30LP/RSMSL
TV Bracket
30T
TV Bracket
30SJ/RSMSS
TV Bracket
Screw
