PHABRIX®
®
ADVANCED FORMATS
The formats option adds additional formats available from the
drop down menu.
Revision
02/14
The advanced formats option
available for the SxA and
SxE adds a variety of new formats to the standard set of
76 currently available. These include 4:2:2 YUV, 4:4:4
RGB, and 4:4:4 YUV at 10/12 bit and 3G level A and B.
Once the option code has been entered, the new formats
will be shown in the generator selection window as
exemplified in the diagram right.
Please note that the PHABRIX
®
SxD has these formats plus
additional formats associated with dual link usage,
ADDITIONAL FORMATS AVAILABLE
3 Gb/s
60
59.94
50
30
29.97
25
24
23.98
SMPTE 425-A
SMPTE 296M
1280 x 720
4:4:4 (R’G’B’), 4:4:4:4 (R’G’B’ +A)/10-bit
4:4:4 (Y’C’
B
C’
R
), 4:4:4:4 (Y’C’
B
C’
R
+A)/10-bit
P
P
P
P
P
P
P
P
SMPTE 274M
1920 x 1080
4:4:4 (R’G’B’), 4:4:4:4 (R’G’B’ +A)/10-bit
4:4:4 (Y’C’
B
C’
R
), 4:4:4:4 (Y’C’
B
C’
R
+A)/10-bit
I
I
I
P,sF
P,sF
P,sF
P,sF
P,sF
SMPTE 274M
1920 x 1080
4:4:4 (R’G’B’)/12-bit
4:4:4 (Y’C’
B
C’
R
)/12-bit
I
I
I
P
P
P
P
P
SMPTE 428-9
2048 x 1080
4:4:4 (X’Y’Z’)/12-bit
P,sF
P,sF
SMPTE 274M
1920 x 1080
4:2:2 (Y’C’
B
C’
R
)/12-bit
I
I
I
P,sF
P,sF
P,sF
P,sF
P,sF
3 Gb/s
Mapping of 2 x SMPTE 292M HD SDI Interfaces
BLUE
formats are standard on the SxD and as an option on the SxA and SxE
TURQUOISE
formats on SxA and SxE as SMPTE 425-B carrying 1 x SMPTE 372M dual link payload
RED
formats can be detected by the Sx but not fully handled
SMPTE 425-B
1 x SMPTE-372M dual-link payload
Link Type
Reference Standard
Resolution
Rates
1.485 Gb/s
60
59.94
50
30
29.97
25
24
23.98
SMPTE 372M
SMPTE 274M
1920 X 1080
4:2:2 (Y’C’
B
C’
R
)/10-bit
P
P
P
1920 x 1080
4:4:4 (R’G’B’), 4:4:4:4 (R’G’B’ +A)/10-bit
4:4:4 (R’G’B’)/12-bit
4:4:4 (Y’C’
B
C’
R
), 4:4:4:4 (Y’C’
B
C’
R
+A)/10-bit
4:4:4 (Y’C’
B
C’
R
)/12-bit
4:4:2 (Y’C’
B
C’
R
)/12-bit
SMPTE 428-9
2048 x 1080
4:4:4 (X’Y’Z’)/12-bit
P,sF
P,sF
I
I
I
P,sF
P,sF
P,sF
P,sF P,sF
*Specifications and features described herein are subject to change without prior notice.
Please consult our website www.phabrix.com for the latest data.
PHABRIX is a registered trademark.
ORDERING INFORMATION
Product Code
PHSXOF
