- - 2 -
1. ORDERING GUIDE, SERIAL INPUT TRANSMITTER
Configure a model number in this format: LTS600, CBL04
LTS6…Transmitter with 4-20 mA, 0-20 mA
or 0-10V isolated analog output,
RS232 or RS485 serial data input, and
dual 120 mA solid state relays. Default
jumpered for RS232.
LTSE6E… Transmitter with 4-20 mA, 0-20
mA or 0-10V isolated analog output,
Ethernet serial data input, and dual 120
mA solid state relays.
Power
0.............................85-264 Vac or 90-300 Vdc
1.................................12-30 Vac or 10-48 Vdc
ACCESSORIES
CBL04……RS232 cable, two 3-pin connec-
tors on transmitter end, DB9 con-
nector on computer end.
CBL02……USB to DB9 adapter cable. Can be
used with CBL01 or CBL04.
2. TABLE OF CONTENTS
1. ORDERING GUIDE, SERIAL INPUT TRANSMITTER .......................................................... 2
2. TABLE OF CONTENTS ....................................................................................................... 2
3. INTRODUCTION, SERIAL INPUT TRANSMITTER.............................................................. 3
4. RECEIVING & UNPACKING YOUR TRANSMITTER ........................................................... 3
5. SAFETY CONSIDERATIONS .............................................................................................. 4
6. TRANSMITTER FIELD WIRING ......................................................................................... 5
7. PROGRAMMING YOUR TRANSMITTER............................................................................ 6
8. CHANGING JUMPER SETTINGS ....................................................................................... 8
9. DUAL RELAY OPERATION ............................................................................................... 10
10. MODBUS PROTOCOL TRANSMITTER COMMUNICATIONS.............................................. 12
11. CUSTOM ASCII PROTOCOL TRANSMITTER COMMUNICATIONS .................................... 17
12. SPECIFICATIONS, SERIAL INPUT TRANSMITTER ............................................................ 20
13. WARRANTY ...................................................................................................................... 24
