SeaLINK+16.VC User Manual
Electrical Characteristics
Features
Supports front or rear rack mounting or desktop use
Provides 16 RJ45 serial ports with status LEDs
Allows RS-232 or RS-485 pin out selection on port-by-port basis
Includes two fully-rated (500mA) USB 1.1 downstream ports
Integrates transmit and receive LED indicators on each port
Includes front and rear status LED to indicate unit power
9-30V input power option available for OEM volume opportunities
Specifications
Temperature Range
Operating:
-0°C – 70°C
Storage:
-50°C – 105°C
Power Requirements
+5VDC @ 3A
Physical Dimensions
Length Width* Height
7.0” 16.8”
1.7”
(1U)
17.78 cm
42.56 cm
4.32 cm
* Width excludes rack-mount ears.
Manufacturing
All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are
100% electrically tested. These printed circuit boards are solder mask over bare
copper or solder mask over tin nickel.
