Specifications
Sealevel Systems ULTRA 485.PCI Page
10
Specifications
Environmental Specifications
Specification Operating Storage
Temperature
Range
0º to 70º C
(32º to 158º F)
-50º to 105º C
(-58º to 221º F)
Humidity Range
10 to 90% R.H.
Non-Condensing
10 to 90% R.H.
Non-Condensing
Manufacturing
All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are 100% electrically tested. These
printed circuit boards are solder mask over bare copper or solder mask over tin nickel.
Power Consumption
Supply line
+5 VDC
Rating
480 mA
Physical Dimensions
Board length
4.9 inches
(12.446 cm)
Board Height including Goldfingers
2.80 inches
(7.112 cm)
Board Height excluding Goldfingers
2.475 inches
(6.287cm)
