Installation
Sealevel Systems VERSA COMM+4.LPCI Page 5
Physical Installation
The adapter can be installed in any 3.3 or 5V PCI expansion slot and contains several jumper straps for each port
that must be set for proper.
Do not install the Adapter in the machine until the software has been fully installed.
1. Turn off PC power. Disconnect the power cord.
2. Remove the PC case cover.
3. Locate an available PCI slot and remove the blank metal slot cover.
4. Gently insert the PCI adapter into the slot. Make sure that the adapter is seated properly.
5. Replace the screw. (This is required to ensure FCC Part 15 compliance.)
6. Install the cable. (CA199 or CA200)
7. Replace the cover.
8. Connect the power cord
Installation is finished.
