Electrical characteristics – Impulse 2108 User Manual
Page 8
© Sealevel Systems, Inc.
- 6 -
SeaLINK+232.PC User Manual
Electrical Characteristics
Features
Dual bracket mountable and low profile
No system resources are required (i.e. I/O ports or IRQs)
Input power protection
Specifications
Temperature Range
Operating:
-0°C – 70°C
Storage:
-50°C – 105°C
Power Requirements
+5VDC @ 50 mA
Physical Dimensions (excluding bracket)
Length:
2.578 inches
(6.548 cm)
Height:
1.310 inches
(3.327 cm)
Manufacturing
All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are
100% electrically tested. These printed circuit boards are solder mask over bare
copper or solder mask over tin nickel.
