© Sealevel Systems, Inc. - 12 - REL-32.PCI User Manual
Electrical Characteristics
Features
32 SPST Reed relays
Two DB-37 Male connectors (CA172 cable)
Highly reliable 10 VA DIP reed relays utilized
Multiple adapters can reside in same computer
PCI 2.1 Bus compliant
Specifications
Output Relays
Contact Max Power Rating: 10 W
Contact Voltage Maximum: 100 VDC/VAC
Contact Current Maximum: .5A AC/DC RMS
Contact Resistance, Initial: .15
Ω
Rated Life:
• Low Load: 200 Million Closures
• Maximum Load: 100 Million Closures
Contact Speed:
• Operate: .5 mS
• Release: .5 mS
• Bounce: .5 mS
Maximum Operating Speed: 600 Hz
Temperature Range
Operating: 0°C – 70°C
Storage: -50°C – 105°C
Power Requirements
+5VDC @ 560 mA
Physical Dimensions
PCB Length: 6.60” (16.764 cm)
PCB Height: 4.20” (10.668 cm, including Gold fingers)
Manufacturing
All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are
100% electrically tested. These printed circuit boards are solder mask over bare
copper or solder mask over tin nickel.
