PLC-16.PCI User Manual
Optional Cable Pin Assignments (Item# CA184)
Part Number CA184 is an optional cable for use with the PLC-16.PCI. The CA184
has an HD44 connector that breaks out to one DB37 Female connector for Inputs
and one DB37 Male connector for Outputs. This cable was designed to make our
products more easily integrated into systems that may have previously used Sealevel
legacy I/O interface products. The CA184 cable mimics several of the pin-out
options found on Sealevel PCI and ISA legacy products and provides a direct
connection to the 37 pin Terminal Block, Part Number TB02-KT. The following
tables show the pin out for this cable.
Input Port Pin Assignments (DB37 Female)
Port A Bit Input
D0 3,22
D1 4,23
D2 5,24
D3 6,25
D4 7,26
D5 8.27
D6 9,28
D7 10,29
Output Port Pin Assignments (DB37 Male)
Port C Bit Normally Closed
Common
Normally Open
D0 (K1)
1
2
3
D1 (K2)
4
5
6
D2 (K3)
7
8
9
D3 (K4)
10
11
12
D4 (K5)
22
23
24
D5 (K6)
25
26
27
D6 (K7)
28
29
30
D7 (K8)
31
32
33
