Railway Computers
EPM-3552 Specifications
EPM-DK01 Specifications
Display
Graphics Controller: DisplayLink DL-195
VGA Interface: 15-pin D-sub connector (female)
DVI Interface: 24-pin DVI-I connector (female)
Resolution: Up to 1920 x 1600 (2048 x 1152 for wide screen)
resolution
Physical Characteristics
Weight: 130 g
Dimensions: 104 x 121 x 34 mm (4.09 x 4.76 x 1.34 in)
Environmental Limits
Operating Temperature: -25 to 55°C (-13 to 131°F), EN 50155 Class T1
PCI Express Mini Slot
Interface: PCI-Express V1.0 (one lane)
USB 2.0 Bus SIM Card Holder: Reserved for Cellular applications
Mini PCI Slot
Interface: PCI
Bus Frequency: 32-bit, 33 MHz PCI
Physical Characteristics
Weight: 117 g
Environmental Limits
Operating Temperature: -40 to 70°C (-40 to 158°F)
PCI Express Mini Slot
Interface:
• Slot 1: PCI-Express V1.0 (one lane) / USB 2.0
• Slot 2: USB 2.0
USB 2.0 Bus SIM Card Holder: Reserved for cellular applications
EPM-DK02 Specifications
Physical Characteristics
Weight: 125 g
EPM-DK03 Specifications
PCI Express Mini Slot
Interface:
• Slot 1: PCI-Express V1.0 (one lane) / USB 2.0
• Slot 2: USB 2.0
USB 2.0 Bus SIM Card Holder: Reserved for cellular applications
Physical Characteristics
Weight: 220 g
Dimensions: 104 x 121 x 34 mm (4.09 x 4.76 x 1.34 in)
Environmental Limits
Operating Temperature: -25 to 55°C (-13 to 131°F), EN 50155 Class T1
GPS Interface
Receiver Types:
• 50-channel u-blox 6 LEA-6 receiver
• GPS L1 C/A code
• GALILEO L1 open service (with upgrade)
• SBAS: WAAS, EGNOS, MSAS, GAGAN
Acquisition:
• Cold starts: 28s
• Warm starts: 28s
• Aided starts: 1s
• Hot starts: 1s
Sensitivity:
• Tracking: -160 dBm
• Reacquisition: -160 dBm
• Cold starts: -147 dBm
Timing accuracy:
• RMS: 30 ns
• 99%: <60 ns
• Granularity: 21 ns
Accuracy:
• Position: 2.5m CEP
• SBAS: 2.0m CEP
Protocols: NMEA, UBX binary, max. update rate: 5Hz (ROM version )
Time Pulse: 0.25Hz to 1KHz
Velocity Accuracy: 0.1 m/s
Heading Accuracy: 0.5 degrees
A-GPS: Supports AssistNow Online and AssistNow Offline, OMA SUPL
compliant
Operational Limits: Velocity:500m/s (972 knots)
EPM-3338 Package List
• 1 EPM-DK03 Expansion Module
• 1 V2400 WiFi Accessory Package
• 1 V2400 HSPA Cellular Accessory Package
• 1 Quick Installation Guide (printed)
• 1 Software Installation DVD
