High Performance Signal Conditioners DSCA
For information call 800-444-7644 186
©1995-2009 Dataforth Corporation, All Rights Reserved ISO9001:2000-Registered QMS
STRAIN GAGE INPUT MODULES Page 200
OUTPUT
MODEL INPUT EXCITATION RANGE †
DSCA38-01 ±10mV Full Bridge Input, (3mV/V) +3.333V 1
DSCA38-02 ±30mV Full Bridge Input, (3mV/V) +10.0V 1
DSCA38-03 ±10mV Half Bridge Input, (3mV/V) +3.333V 1
DSCA38-04 ±30mV Half Bridge Input, (3mV/V) +10.0V 1
DSCA38-05 ±20mV Full Bridge Input, (2mV/V) +10.0V 1
DSCA38-06 ±33.3mV Full Bridge Input, (10mV/V) +3.333V 1
DSCA38-07 ±100mV Full Bridge Input, (10mV/V) +10.0V 1
DSCA38-08 ±10mV Full Bridge Input, (3mV/V) +3.333V 2, 3, 4
DSCA38-09 ±30mV Full Bridge Input, (3mV/V) +10.0V 2, 3, 4
DSCA38-10 ±10mV Half Bridge Input, (3mV/V) +3.333V 2, 3, 4
DSCA38-11 ±30mV Half Bridge Input, (3mV/V) +10.0V 2, 3, 4
DSCA38-12 ±20mV Full Bridge Input, (2mV/V) +10.0V 2, 3, 4
DSCA38-13 ±33.3mV Full Bridge Input, (10mV/V) +3.333V 2, 3, 4
DSCA38-14 ±100mV Full Bridge Input, (10mV/V) +10.0V 2, 3, 4
DSCA38-15 0 to +10mV Full Bridge Input, (3mV/V) +3.333V 2, 3, 4
DSCA38-16 0 to +30mV Full Bridge Input, (3mV/V) +10.0V 2, 3, 4
DSCA38-17 0 to +10mV Half Bridge Input, (3mV/V) +3.333V 2, 3, 4
DSCA38-18 0 to +30mV Half Bridge Input, (3mV/V) +10.0V 2, 3, 4
DSCA38-19 0 to +20mV Full Bridge Input, (2mV/V) +10.0V 2, 3, 4
DSCA38-20 0 to +33.3mV Full Bridge Input, (10mV/V) +3.333V 2, 3, 4
DSCA38-21 0 to +100mV Full Bridge Input, (10mV/V) +10.0V 2, 3, 4
CURRENT OUTPUT MODULES Page 202
MODEL
INPUT RANGE OUTPUT RANGE
DSCA39-01 0V to +10V 4mA to 20mA
DSCA39-02 –10V to +10V 4mA to 20mA
DSCA39-03 0V to +10V 0mA to 20mA
DSCA39-04 –10V to +10V 0mA to 20mA
DSCA39-05 0mA to 20mA 0mA to 20mA
DSCA39-07 –10V to +10V -20mA to +20mA
DSCA Selection Guide (Continued)
POTENTIOMETER INPUT MODULES Page 196
MODEL
INPUT RANGE OUTPUT RANGE †
DSCA36-01 100 Ω 2, 3, 4
DSCA36-02 500 Ω 2, 3, 4
DSCA36-03 1k Ω 2, 3, 4
DSCA36-04 10k Ω 2, 3, 4
THERMOCOUPLE INPUT MODULES Page 198
MODEL
TYPE ‡ INPUT RANGE OUTPUT RANGE †
DSCA37J-01 J –100°C to +760°C (–148°F to +1400°F) 2, 3, 4
DSCA37K-02 K –100°C to +1350°C (–148°F to +2462°F) 2, 3, 4
DSCA37T-03 T –100°C to +400°C (–148°F to +752°F) 2, 3, 4
DSCA37E-04 E 0°C to +900°C (+32°F to +1652°F) 2, 3, 4
DSCA37R-05 R 0°C to +1750°C (+32°F to +3182°F) 2, 3, 4
DSCA37S-06 S 0°C to +1750°C (+32°F to +3182°F) 2, 3, 4
DSCA37B-07 B 0°C to +1800°C (+32°F to +3272°F) 2, 3, 4
DSCA37N-08 N –100°C to +1300°C (–148°F to +2372°F) 2, 3, 4
ANALOG VOLTAGE INPUT MODULES, 3kHz BW Page 204
MODEL
INPUT RANGE OUTPUT RANGE †
DSCA40-01 –10mV to +10mV 1
DSCA40-02 –50mV to +50mV 1
DSCA40-03 –100mV to +100mV 1
DSCA40-04 –10mV to +10mV 2, 3, 4
DSCA40-05 –50mV to +50mV 2, 3, 4
DSCA40-06 –100mV to +100mV 2, 3, 4
DSCA40-07 0 to +10mV 2, 3, 4
DSCA40-08 0 to + 50mV 2, 3, 4
DSCA40-09 0 to +100mV 2, 3, 4
DSCA41-01 –1V to +1V 1
DSCA41-02 –5V to +5V 1
DSCA41-03 –10V to +10V 1
DSCA41-04 –1V to +1V 2, 3, 4
DSCA41-05 –5V to +5V 2, 3, 4
DSCA41-06 –10V to +10V 2, 3, 4
DSCA41-07 –20V to +20V 1
DSCA41-08 –20V to +20V 2, 3, 4
DSCA41-09 –40V to +40V 1
DSCA41-10 –40V to +40V 2, 3, 4
DSCA41-11 0 to +1V 2, 3, 4
DSCA41-12 0 to +5 V 2, 3, 4
DSCA41-13 0 to +10V 2, 3, 4
DSCA41-14 0 to +20V 2, 3, 4
DSCA41-15 0 to +40V 2, 3, 4
2-WIRE TRANSMITTER INTERFACE MODULES Page 206
MODEL
INPUT RANGE OUTPUT RANGE †
DSCA42-01 4mA to 20mA 0V to +10V & 3, 4
DSCA42-02 4mA to 20mA 2V to +10V
GENERAL PURPOSE INPUT MODULES, DC EXCITATION Page 208
MODEL
INPUT RANGE OUTPUT RANGE †
DSCA43-01 –1V to +1V 1
DSCA43-02 –2V to +2V 1
DSCA43-03 –3V to +3V 1
DSCA43-04 –4V to +4V 1
DSCA43-05 –5V to +5V 1
DSCA43-06 –6V to +6V 1
DSCA43-07 –7V to +7V 1
DSCA43-08 –8V to +8V 1
DSCA43-09 –9V to +9V 1
DSCA43-10 –10V to +10V 1
DSCA43-11 –1V to +1V 2, 3, 4
DSCA43-12 –2V to +2V 2, 3, 4
DSCA43-13 –3V to +3V 2, 3, 4
DSCA43-14 –4V to +4V 2, 3, 4
DSCA43-15 –5V to +5V 2, 3, 4
DSCA43-16 –6V to +6V 2, 3, 4
DSCA43-17 –7V to +7V 2, 3, 4
DSCA43-18 –8V to +8V 2, 3, 4
DSCA43-19 –9V to +9V 2, 3, 4
DSCA43-20 –10V to +10V 2, 3, 4
