Isolated Analog Signal Conditioning Products SCM5B
SCM5B
©1995-2009 Dataforth Corporation, All Rights Reserved ISO9001:2000-Registered QMS
ACCESSORIES Starts on Page 48
MODEL DESCRIPTION
SCMPB01 Non-multiplexed, 16-channel backpanel.
SCMPB01-1 Non-multiplexed, 16-channel backpanel, no CJC.
SCMPB01-2 SCMPB01 with DIN rail mounting option.
SCMPB01-3 SCMPB01-1 with DIN rail mounting option.
SCMPB02 Multiplexed, 16-channel backpanel.
SCMPB02-1 Multiplexed, 16-channel backpanel, no CJC.
SCMPB02-2 SCMPB02 with DIN rail mounting option.
SCMPB02-3 SCMPB02-1 with DIN rail mounting option.
SCMPB03 Single channel backpanel.
Mounting hardware not included.
SCMPB03-2 SCMPB03 with DIN rail mounting hardware.
SCMPB04 Dual channel backpanel.
Mounting hardware not included.
SCMPB04-1 Dual channel backpanel, DIN rail mount, no CJC.
SCMPB04-2 SCMPB04 with DIN rail mounting hardware.
SCMPB04-3 SCMPB04-1 with DIN rail mounting hardware.
SCMXBEFE Base element with snap foot.
SCMXBE Base element without snap foot.
SCMXSE Side element.
SCMXVS Connection pins.
SCMPB05 Non-multiplexed, 8-channel backpanel.
SCMPB05-1 Non-multiplexed, 8-channel backpanel, no CJC.
SCMPB05-2 SCMPB05 with DIN rail mounting option.
SCMPB05-3 SCMPB05-1 with DIN rail mounting option.
SCMPB06 Multiplexed, 8-channel backpanel.
SCMPB06-1 Multiplexed, 8-channel backpanel, no CJC.
SCMPB06-2 SCMPB06 with DIN rail mounting option.
SCMPB06-3 SCMPB06-1 with DIN rail mounting option.
SCMPB07 8-channel high-density backpanel.
SCMPB07-1 SCMPB07, no CJC.
SCMPB07-2 SCMPB07, DIN rail mount.
SCMPB07-3 SCMPB07, no CJC, DIN rail mount.
SCMXEV Single channel SCM5B evaluation board.
SCMXCA004-xx System interface cable for both analog backpanels.
SCMXRK-002 19-inch metal rack for mounting analog backpanels.
SCMXIF Ribbon cable to screw terminal interface board.
SCMXIF-DIN Universal Interface Board.
SCMXCJC Encapsulated cold junction compensation circuit.
SCM5BPT Pass Thru.
SCMXJP-003 Package of 10 jumpers.
SCMXFS-003 Package of 10, 4A fuses.
SCMXR1 Precision 20 Ω resistor for SCM5B32 and SCM5B42.
SCM5B-PROTO Breadboard Kit.
SCMXRAIL1-XX DIN EN50022-35x7.5 (slotted steel), length -XX
in meters.
SCMXRAIL2-XX DIN EN50035-G32 (slotted steel), length -XX
in meters.
SCMXRAIL3-XX DIN EN50022-35x15 (slotted steel), length -XX in meters.
SCMXPRT-001 Power supply, 1A, 5VDC, 120VAC U.S.
SCMXPRT-001D SCMXPRT-001 with DIN rail mounting option.
SCMXPRE-001 Power supply, 1A, 5VDC, 220VAC European.
SCMXPRE-001D SCMXPRE-001 with DIN rail mounting option.
SCMXPRT-003 Power supply, 3A, 5VDC, 120VAC U.S.
SCMXPRE-003 Power supply, 3A, 5VDC, 220VAC European.
NOTES:
‡ THERMOCOUPLE ALLOY COMBINATIONS
Standards: DIN IEC 584, ANSI MC96-1-82, JIS C 1602-1981
TYPE MATERIAL
J Iron vs. Copper-Nickel
K Nickel-Chromium vs. Nickel-Aluminum
T Copper vs. Copper-Nickel
E Nickel-Chromium vs. Copper-Nickel
R Platinum-13% Rhodium vs. Platinum
S Platinum-10% Rhodium vs. Platinum
B Platinum-30% Rhodium vs.Platinum-6%Rhodium
C Tungsten-5% Rhenium vs. Tungsten-26% Rhenium
N Nickel-14.2% Chromium-1.4% Silicon vs. Nickel-4.4%
Silicon-0.1% Magnesium
**RTD STANDARDS
TYPE ALPHA COEFFICIENT DIN JIS IEC
100 Ω Pt 0.00385 DIN 43760 JIS C 1604-1989 IEC 751
120 Ω Ni 0.00672
10 Ω CU 0.004274
1. – 5V to +5V NONE SCM5B30-01
2. – 10V to +10V D SCM5B30-01D
3. 0V to +5V NONE SCM5B30-04
4. 0V to +10V D SCM5B30-04D
5. 4 to 20mA C SCM5B33-01C
6. 0 to 20mA E SCM5B33-01E
7. 0 to 1mA B SCM5B33-01B
Output Range Part No. Suffix Example
† OUTPUT RANGES AVAILABLE
SCM5B Selection Guide (Continued)
