SCM7B

Visit our website www.dataforth.com

83

Isolated Process Control Signal Conditioning Products

SCM7B

Specifications

Typical at 25°C and +24VDC

Input

Signal Range

-1V to +1V

-10V to +40V

Bias Current

±1nA

±0.1nA

Resistance

Normal

50M

500k

min

Power Off

30k

min

500k

min

Overload

30k

min

500k

min

Protection

Continuous

120Vrms max

*

Transient

ANSI/IEEE C37.90.1

*

Output

Signal Range

(1)

†

†

Effective Available Power

(1)

40mW

*

Resistance

<1

*

Protection

Continuous Short-to-Ground

*

Voltage/Current Limit

±12V, ±14mA

*

CMV (Input-to-Output)

Continuous

1500Vrms max

*

Transient

ANSI/IEEE C37.90.1

*

CMRR (50 or 60Hz)

110dB

100dB

Accuracy

(2)

±0.03% Span typical,

*

±0.1% Span max

Nonlinearity

(3)

±0.01% Span typical,

*

±0.02% Span max

Stability (-40°C to +85°C)

Gain

±35ppm/°C

±55ppm/°C

Input Offset

±0.5µV/°C

±5µV/°C

Zero Suppression

±0.005%(V

z

)

(4)

/°C

*

Output Offset

±0.002% Span/°C

*

Noise

Peak at 5MHz B/W

2mV

*

RMS at 10Hz to 100kHz B/W

1mV

*

Peak at 0.1Hz to10Hz B/W

1µV RTI

*

Frequency and Time Response

Bandwidth, -3dB

10kHz

*

NMR

80dB/decade >10kHz

*

Step Response, 90% Span

50µs

*

Supply Voltage

14 to 35VDC

*

Current

(1)

12mA

*

Sensitivity

±0.0001%/%V

S

*

Mechanical Dimensions

2.13" x 1.705" x 0.605" max

*

(h)(w)(d)

54.1mm x 43.3mm x 15.4mm max

*

Environmental

Operating Temperature Range

-40°C to +85°C

*

ATEX Group II, Category 3

-20°C to +40°C

*

Storage Temperature Range

-40°C to +85°C

*

Relative Humidity

0 to 95% noncondensing

*

Emissions EN61000-6-4

ISM, Group 1

*

Radiated, Conducted

Class A

*

Immunity EN61000-6-2

ISM, Group 1

*

RF

Performance A ±0.5% Span Error

*

ESD, EFT, Surge, Voltage Dips

Performance B

*

Module SCM7B40 SCM7B41

NOTES:

* Specification same as preceding model.

(1) Output Range and Supply Current specifications are based on minimum output load resistance.

Minimum output load resistance is calculated by V

OUT

2

/P

E

, where P

E

is the Output Effective Available

Power that guarantees output range, accuracy, and linearity specifications.

(2) Accuracy includes the effects of repeatability, hysteresis, and linearity.

(3) Nonlinearity is calculated using the best-fit straight line method.

(4) V

Z

is the nominal input voltage that results in a 0V output.

Ordering Information

Model

Input Range

SCM7B40-02

0 to +100mV

SCM7B40-03

0 to +1V

SCM7B40-07

±100mV

SCM7B40-08

±1V

SCM7B41-01

0 to +10V

SCM7B41-02

±5V

SCM7B41-03

±10V

SCM7B41-04

0 to +5V

SCM7B41-05

0 to +20V

SCM7B41-06

0 to +40V

Output Range Part No. Suffix

Example

+1 to +5V

NONE

SCM7B40-02

0 to +5V

A

SCM7B40-02A

0 to +10V

D

SCM7B40-02D

†

††

†

†

Output Ranges Available
