DSCT
Visit our website www.dataforth.com 203
DIN Rail Mount Two-Wire Transmitters
DSCT
Specifications
Input Range 0-20mA or 4-20mA
Current Conversion Resistor 50.00 Ω
Input Protection
Continuous 240Vrms max
Transient ANSI/IEEE C37.90.1
CMV, Input to Output
Continuous 1500Vrms max
Transient ANSI/IEEE C37.90.1
CMR (50Hz or 60Hz) 160dB
NMR (-3dB at 100Hz) 80dB/decade Above 100Hz
Adjustability ±10% Zero and Span
Accuracy (1) ±0.03%
Conformity ±0.01%
Stability
Offset ±30ppm/°C
Gain ±90ppm/°C
Noise
Output, 100kHz 3µArms
Bandwidth, –3dB 100Hz
Response Time, 90% Span 5ms
Output Range 4mA to 20mA
Output Limits
Under-range 2.8mA
Over-range 29mA
Output Protection
Reverse Polarity Continuous
Over-voltage 240Vrms Continuous
Transient ANSI/IEEE C37.90.1
Loop Supply Voltage 10.8V to 60V
Loop Supply Sensitivity ±0.0005%/V
Turn-On Delay 400ms
Environmental
Operating Temp. Range –40°C to +80°C
Storage Temp. Range –40°C to +80°C
Relative Humidity 0 to 95% Noncondensing
Emissions EN50081-1, ISM Group 1,
Class A (Radiated, Conducted)
Immunity EN50082-1, ISM Group 1,
Class A (ESD, RF, EFT)
Mechanical Dimensions 2.95" x 0.89" x 4.13”
(h)(w)(d) (75mm x 22.5mm x 105mm)
Mounting DIN EN 50022 –35x7.5 or –35x15 rail
Module DSCT32
Typical at T
A
=+25°C and +24V loop voltage
NOTES:
(1) Includes nonlinearity, hysteresis and repeatability.
Ordering Information
Model Input Range
DSCT32-01 4-20mA
DSCT32-02 0-20mA
