Embedded Automation Computers
Features
UNO-4673A
UNO-4683
ƒ IEC 61850-3 and IEEE 1613 compliant for substation automation applications
ƒ Onboard Intel Atom 1.66 GHz / Core i7 2.0 GHz processor
ƒ 2 x RS-232/422/485 isolated serial ports with automatic flow control and
128KB FIFO
ƒ 2 x 10/100/1000 Base-T (supports teaming function) and 4 x 10/100 Base-T
ƒ Supports 1 x internal CF card and 1 x 2.5" SATA HDD
ƒ 6 x USB 2.0 (1 x internal) and 3 x Domain I/O expansions
ƒ Rear wiring, rich system & I/O LED status indicators
ƒ Windows CE6.0(UNO-4673 only), Windows XP Embedded SP2, Win7, WES7,
and Linux
ƒ Fanless design with no internal cabling
ƒ Isolation power design with wide AC / DC input range
ƒ Isolation between chassis and power ground
ƒ One internal USB for dongle and flash drive
Intel ® Atom ™ D510 / Core ™ i7 Substation
Computers with 6 x LAN, 2 x COM
and 3 x Expansion Slots
Introduction
UNO-4673A and UNO-4683 are compliant with the hardware requirements of IEC 61850-3, which defines the international standards of network and system communications in
power substations. Featuring fanless designs with built-in isolated PSU and 3 expansion slots for I/O plug-in cards, UNO-4673A and UNO-4683 are suitable for harsh environment
applications. The rear I/O connection and LEDs on front panel for all ports and modes highly simplify monitoring for operation and maintenance.
Specifications
General
ƒ Certifications IEC 61850-3, IEEE 1613, CE, FCC Class A, UL, CCC
ƒ Dimensions (W x D x H) 2U (440 x 280 x 88) mm (17.3" x 11" x 3.4")
fits into standard 19 inch rack
ƒ Enclosure SECC+Aluminum
ƒ Mounting 2U Rackmount
ƒ Power Consumption 24W/45W (Typical)
ƒ Power Requirements AC : 100 ~ 240 V
AC
(47 ~ 63 Hz)
DC : 106 ~ 250 V
DC
With isolation protection, AT
ƒ Weight 6.0 kg
ƒ OS Support Windows CE6.0(UNO-4673 only), Windows XP
Embedded SP2, Win7, WES7, and Linux
ƒ System Design Fanless with no internal cabling
ƒ Remote Management Built-in Advantech DiagAnywhere agent on Windows
CE/XPe
System Hardware
ƒ CPU Intel Dual Core Atom D510 1.66 GHz / Core i7 2.0 GHz
ƒ Memory 2G DDR2 SDRAM/4G DDR3 SDRAM built-in
ƒ Indicators LEDs for Power, IDE, Alarm for battery backup SRAM,
Diagnosis (programmable), LAN (Active, Status) and
Serial (Tx, Rx)
ƒ Keyboard/Mouse 2 x PS/2 connector for Keyboard & Mouse
ƒ Storage
CF 1 x internal type I/II CompactFlash ® slot
HDD Built-in one 2.5" SATA HDD bracket*
*RAID capable with 2nd HDD kit
ƒ Display 4683A DB15 VGA connector, 1600x1200 @ 85 Hz
4683 series 1x DVI-I, 1920x1080@60HZ
ƒ Watchdog Timer Programmable 7-tier event handler, from 1 to 255
seconds for each tier
ƒ Battery Backup SRAM 1 MB
ƒ Relay:
Relay output:
Form C
Contact: 5A@250V
AC
\5A@30V
DC
I/O Interface
ƒ Serial Ports 2 x DB-9
Automatic RS-485 data flow control
4000 V
DC
EFT protection & 2000 V
DC
isolation
ƒ Serial Port Speed RS-232: 50 ~ 115.2 kbps
RS-422/485: 50 ~ 921.6 kbps (Max.)
ƒ LAN 2 x 10/100/1000 Base-T RJ-45 ports,teaming function
supported
4 x 10/100Base-T RJ-45 ports
ƒ Audio Line-out
ƒ USB Ports 6 x USB, UHCI, Rev. 2.0 compliant
2 x Front, 3 x Rear and 1 x Internal ports
ƒ Expansion 3 x Domain I/O expansions (Only slot 1 supports PCIe
resource)
Environment
ƒ Humidity 95% @ 40°C (non-condensing)
ƒ Operating Temperature IEC 60068-2-2 with 100% CPU/ I/O loading, 48 hrs
-20 ~ 70°C (optional for -40°C)
ƒ Operating Humidity 20 ~ 95% (non-condensing)
ƒ Shock Protection HDD: 1.0G half sine, 11ms
ƒ Vibration Protection IEC 60068-2-64 (Random 1 Oct./min, 1hr/axis.)
HDD 1Grms @ 5!500Hz
Ordering Information
ƒ UNO-4673A-A33E Intel Atom 1.66 GHz, 2 GB RAM Automation Computer
ƒ UNO-4683-D34E Core i7 2.0 GHz, 4 GB RAM Automation Computer
Accessories
ƒ UNOP-1000I-AE Expansion card for standard PCI and Mini PCI
ƒ UNOP-1000J-AE Expansion card for standard PCI-104 and Mini PCIe
ƒ UNOP-1514C-AE 4-port Fiber Optic LAN card
ƒ UNOP-1618D-AE 8-port RS-232/422/485 w/EFT protection
ƒ UNOP-1628D-AE 8-port RS-232/422/485 w/Iso and EFT
ƒ UNOP-1624D-AE 4-port RS-232/422/485 w/Iso and EFT, 1-port IRIG-B
ƒ PCLS-DIAGAW10 Advantech Remote Monitoring & Diagnosis Utility
ƒ UNOP-1901-AE HDD Expansion kit for UNO-4673A,4683
RoHS
COMPLIANT
2002/95/EC
NEW
