Programmable Automation Controllers
Features
15-16
APAX-6572
APAX-6572R
Intel ® Atom™ D510 1.66 GHz, 2 GB RAM
Controller with 3 x LAN, 2 x COM, VGA
Redundant Control System
Specifications
General
ƒ Certification CE, FCC Class A
ƒ Cooling System Fanless
ƒ Mounting DIN-rail, Wall mount (panel mount)
ƒ Dimension (W x H x D) 222 x 155 x 140 mm
ƒ Enclosure Aluminum + SECC, ABS + PC (I/O)
ƒ Weight 2.6 kg (APAX-6572)
2.8 kg (APAX-6572R)
ƒ Power Consumption 35 W @ 24 V
DC
(APAX-6572, Typical, Without I/O
modules)
40 W @ 24 V
DC
(APAX-6572R, Typical, Without I/O
modules)
ƒ Power Requirement 10 ~ 36 V
DC
(e.g +24 V @ 1 A) (Min. 24 W), AT
ƒ Watchdog Timer Programmable 7-tier event handler, from 1 ~ 255
seconds for each tier
ƒ Switchover Timer ≤50 ms (For APAX-6572R)
System Hardware
ƒ CPU Intel Atom D510 1.66 GHz
ƒ Memory 2 GB DDR2 DRAM (onboard)
ƒ Battery Backup SRAM 1 MB
ƒ Watchdog Timer Programmable 7-tier event handler, from 1 ~ 255
seconds for each tier
ƒ LED Indicators Power, CF, LAN (Active, Status), Serial (Tx, Rx)
ƒ Display VGA (DB15 connector), up to 1600 x 1200 @ 85Hz
ƒ Audio Line in, Line out, Mic in
ƒ Storage 1 x internal Type I/II CompactFlash card slot
Software
ƒ Operating System Windows WES7, WES2009, Windows CE
ƒ Control Software C/C++ and .NET library with utility
KW MultiProg (development), ProConOS (kernel)
ƒ Remote Management Built-in Advantech DiagAnywhere agent
Modbus/ASCII master/slave mode
KW MultiProg (development), ProConOS (kernel)
RoHS
COMPLIANT
2002/95/EC
ƒ Intel Atom D510 1.66 GHz CPU
ƒ Onboard 2 GB DDR2 DRAM
ƒ Redundant system with two controllers (master and slave) to ensure
continuous I/O control
ƒ Expands I/O by connecting with APAX-5000 I/O modules
ƒ Supports Windows WES7, WES2009 and Windows CE
ƒ Provides C/C++ and .NET library for I/O control and communication
ƒ Supports real-time control tasks under Windows CE through ProConOS
ƒ 2 x RS-232/422/485 (automatic flow control)
ƒ 3 x 10/100/1000 Mbps LAN, 4 x USB 2.0
I/O Expansion
ƒ Built-in I/O Module 4 (APAX-6572)
Slots 3 (APAX-6572R)
ƒ Connected I/O Modules 32 (max.)*
ƒ Digital Signals 2048 (max.)
ƒ Analog Signals 512 (max.)
Communication
ƒ Serial Ports 2 x RS-232/422/485 (supports automatic RS-485 data
flow control)
ƒ Serial Baud Rate 50 ~ 115.2 kbps
ƒ LAN Ports 3 x RJ-45 Ports, 10/100/1000 Mbps
ƒ USB Ports 4 x USB 2.0
Environment
ƒ Operating Temperature -10 ~ 50°C (when mounted vertically)
ƒ Storage Temperature -40 ~ 70°C
ƒ Operating Humidity 20 ~ 95% (non-condensing)
ƒ Storage Humidity 0 ~ 95% (non-condensing)
ƒ Shock Protection 50 G @ wall mount, half sine, 11 ms
(Conforms to IEC 60068-2-27)
ƒ Vibration Protection 2 Grms @ 5 ~ 500 Hz
(Random, operating, 1hr/axis)
(Conforms to IEC 60068-2-64)
Ordering Information
ƒ APAX-6572-AE Intel Atom D510 1.66 GHz, 2 GB RAM Controller
ƒ APAX-6572R-AE Redundant Control System
Introduction
The APAX-6572 is a high performance controller with an Intel Atom D510 CPU. By installing Windows WES7, WES2009 or Windows CE operating system, it becomes an application
ready platform. It is an ideal open control platform which can be combined with APAX I/O modules, and features flexible I/O expansion, real-time I/O control, and powerful computing
and networking capability through various interfaces.
The APAX-6572R is a redundant system with two controllers, both equipped with high performance CPUs to backup and monitor each other, offering excellent reliability for I/O control.
Master controller performs I/O processing, while the slave controller is automatically synchronizing with master controller to update the latest database information. When the master
controller fails, the slave controller automatically takes over the control responsibility in a short time.
*APAX DI/O modules can use ID number 0 ~ 31, while AI/O modules and counter modules can only use ID numbers 0 ~ 15
