Impulse PMX-090T User Manual
Page 4
iii
PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
Table of Contents
1
General Information .............................................................................. 3
1.1
Product Description ...................................................... 1
1.2
Product Specification ................................................... 2
1.3
Inspection standard for TFT-LCD Panel ........................ 4
1.4
Product Dimension ....................................................... 7
1.5
Ordering Information ................................................... 8
1.6
Packing List ................................................................... 8
2
System Installation ................................................................................ 9
2.1
CPU Board Outline........................................................ 9
2.2
Connector Summary .................................................. 10
2.3
Connector Pin Assignments........................................ 11
2.4
External I/O Overview ................................................ 13
2.5
External I/O Pin Assignment ....................................... 14
2.6
System Mapping ......................................................... 16
2.7
Watchdog Timer ......................................................... 20
3
Driver Installation ................................................................................ 21
3.1
PMX-090T Development Note ................................... 22
3.2
BIOS Default setting ................................................... 24
Warranty
......................................................................................................... 25
