19
PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
IRQ Mapping
IRQ# Description Usage
IRQ0 System Timer *
IRQ1 Keyboard Controller *
IRQ2 Cascade for IRQ8 - 15
IRQ3 USB *
IRQ4 Serial Port 1 *
IRQ5 USB *
IRQ6 Unassigned
IRQ7 Ethernet 10/100M LAN *
IRQ8 Real Time Clock *
IRQ9 USB *
IRQ10 USB *
IRQ11 Audio *
IRQ12 Mouse *
IRQ13 Math Coprocessor *
IRQ14 Hard Disk Controller#1 *
IRQ15 Hard Disk Controller#2 *
DMA Mapping
DMA# Description Usage
DMA0
DMA1
DMA2 Floppy Disk Controller
DMA3
DMA5
DMA6
DMA7
