Impulse ACP-5182 - Manual

06-3
06
Features
Specifications
Inf
ot
ain
m
ent M
ult
i-T
ouc
h P
ane
l S
olu
tio
ns
18.5” WXGA (1366 x 768) Fanless TFT LCD Display ■ ■
Onboard Intel® Dual Core Atom™ D510 Processor ■ ■
Easy-To-Clean: Multi-Touch Window Design (Two-Point) ■ ■
IP-65 Front Bezel & IPx1 Back Chassis ■ ■
Anti-Scratch Surface (7H Hardness) ■ ■
Smart Card Reader/ MSR/ Camera Support (Optional) ■ ■
18.5” Fanless Multi-Touch Computer With Onboard Intel® Dual Core Atom™ D510 Processor
System
Processor Onboard Intel® Dual Core Atom™ D510 1.66 GHz
System Memory DDR2 SODIMM x 1, up to 2GB
LCD/CRT Controller Integrated in Processor
Ethernet 10/100/1000Base-TX, RJ-45 x 2
I/O Port
RS-232 x 1, RS-232/422/485 x 1, USB2.0 x 6 (2 on side; 4 on rear), Line-out x
1, VGA x 1
Storage Disk Drive 2.5" SATA Hard Disk Drive x 1/ CompactFlash™ Slot (Internal) x 1
Expansion Slot Mini card x 2
OS support
Windows® XP (T/S: Single point), Linux Fedora (T/S: Multi-point), Windows® 7
(T/S: Multi-point)
Mechanical
Construction IP-65/ NEMA4 for plastic front bezel, IPx1 for plastic chassis
Mounting VESA 75/100, Wall
Dimension 18.11” x 12.2” x 2.34” (460mm x 310mm x 59.4mm)
Carton Dimension 26” x 19.53” x 7.87” (661mm x 496mm x 200mm)
Gross Weight 16.06 lb (7.3 kg)
Net Weight 11 lb (5kg)
Environmental
Operating Temperature 32°F ~ 104°F (0°C ~ 40°C)
Storage Temperature -4°F ~ 158°F (-20°C ~ 70°C)
Storage Humidity 10%~95% @ 40°C; non-condensing
Vibration 1 g rms/ 5~500 Hz/ Random operation (HDD)
Shock 20 G peak acceleration (11 msec. Duration)
EMC CE/FCC Class A
Power Supply
DC input 70W DC 12V, with AC power adapter with lock (in package)
LCD
Display type 18.5" TFT-LCD, LED
Max Resolution 1366 x 768
Max. Colors 16.7M colors (6/8-bit for R,G,B)
Luminance 300 cd/m 2
Viewing Angle 170°(H), 160°(V)
Back Light LED
Back Light MTBF (hours) 50,000
Touchscreen
Type Projected Capacitive Multi-Touch (Windows® 7)
Light Transmission 90%
ACP-5182
1.3 M Camera
LCD On/Off
Volume +
Volume -
Brightness +
Brightness -
Antenna Antenna
USB2.0 x 2
VESA 75/100
Mounting Holes
Mounting
Holes
Smart Card Reader
LAN x 2 Line-out x 1
RS-232
USB x 2
USB x 2
Power Connector
VGA
Power Switch
RS-232/422/485
2W Speaker 2W Speaker
