PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
2.2 Connector Summary
Table 2-1 Summary Table
Nbr Description Type of Connections Pin nbrs.
J1 CF Master/Slave Switch Slide Switch ON/OFF
J3 USB External USB Connector 6-pin
J4 USB External USB Connector 6-pin
J5 USB (Optional) 2.0mm 5-pin wafer 5-pin
J8 PS/2 Keyboard 2.54mm 5-pin box header 5-pin
J9 PS/2Keyboard External Mini DIN Socket 6-pin
J10 COM2(RS232/422/485) External D-Sub Male Connector 9-pin
J14 VGA 2.0mm 10-pin box header 10-pin
J18 Micro SD Card Socket Micro SD socket
J23 Audio Line-Out 1.25mm Phone Jack
J24 Audio Mic-In 2.0mm 4-pin wafer 4-pin
J25 COM3 (TX, RX) 1.25mm 3-pin wafer 3-pin
J26 COM4 (TX, RX 1.25mm 3-pin wafer 3-pin
J30 SOM CPU Board Socket SOM CPU Board Socket 200-pin
J31 4-Wires Touch connector 1.25mm 4-pin wafer 4-pin
J32 USB (Wi-Fi Optional) Internal USB Connector 6-pin
RJ45 Ethernet External RJ45 Connector 8-pin
PWR Power Connector (5A) External Mini DIN Socket 3-pin
PWR Power Connector (8A) External Power Plug 2-pin
CF1 CF Card Socket CF Type I/II Socket
