Marine Displays and Computers
›
Zone 2 certified for hazardous area applications
›
High performance / low power Intel dual core Atom D525 1.8 GHz CPU
›
Anti-scratch 19-inch sunlight viewable 1000 nits LCD panel
›
Self-health diagnostics software package for remote predictive
maintenance
›
-40 to 60°C extended operation temperature (with built-in Intelligent
Heater)
›
Totally sealed IP66 / NEMA 4X panel computer
›
Fanless, streamlined enclosure for highly efficient heat dissipation
›
Touch screen control button to enable/disable touch screen interface
›
Optional WLAN, 100M Fiber optic connection
EXPC-1319 Series
Introduction
Fanless rugged Zone 2 19-inch 1000 nits LCD panel computer
with touch screen
The EXPC-1319 panel computers are fanless, durable devices made
for both indoor and outdoor hazardous environments. The EXPC-1319
series features the Intel Atom dual core D525 1.8 GHz processor,
with up to 4 GB of memory available to deliver high performance
processing. The EXPC-1319 is Zone 2 certified, and comes with two
electrically isolated, software-selectable RS-232/422/485 serial ports
alongside two Gigabit LAN ports, providing reliable serial and high
speed Ethernet LAN transmissions with full network redundancy.
The EXPC-1319 computers come with a patented, fanless, streamlined
enclosure designed for highly efficient heat dissipation, making this
one of the most reliable industrial platforms available for harsh, hot
outdoor environments like oil and gas fields, or drilling platforms.
In addition, EXPC-1319 computers come with an expanded set of
self-health diagnostics that communicate over SNMP and may also be
ordered with Moxa’s Intelligent Heating Solution (IHS), a heating utility
for use in extremely low temperature (-40°C) environments. Finally,
these computers feature capacitive touchscreen controls with glass-
film-glass bonding, making them scratch- and glare-resistant and easy
to read even during the peak daylight hours.
Appearance
Rear and Bottom Views
Front and Side Views
Control Button x 5
LED Indicator x 6
SSD/CF
Socket Cover
Power Input
(M12, 24 VDC)
LAN Port x 2
(Gigabit, RJ45)
Serial Port x 2
(DB9 Male)
USB 2.0 x 2
(Type A)
VGA Output
