Intel Core i7-2600 3.40GHz 4U Rack-mount ATX Motherboard System
Impulse’s CobraRack-4720 is a high performance 4U rack-mount system based on the SB630-CRM ATX motherboard from premium partner DFI.
Utilising the high performance Intel i7-2600 processor with an impressive clock speed of 3.40GHz, the CobraRack-4720 is capable of handling high-end
computation tasks without breaking a sweat. The Intel i7-2600 also includes an integrated graphics processor, enabling users to save space and money by not
needing to use up an expansion slot for an unnecessary graphics card
As with all our pre-build systems, Impulse not only selects the best industrial grade hardware to ensure your solution is highly reliable and available on a long
term basis but also ensures the system capabilities are suited to all the additional components included in the build therefore maximising performance whilst
controlling thermal and expansion considerations.
Impulse can configure your CobraRack-4720 to match your exact requirements including chassis colour, memory, storage, expansion and a choice of embedded
operating systems. Optional extras include hot-swappable hard drives, optical drives, hardware based RAID and system alarms.
• Revision controlled industrial 4U ATX motherboard rack-mount system
• Intel Core i7-2600 3.40GHz CPU with integrated Intel HD 2000 graphics
• Expansion: 1 x PCI-Express [x16], 1 x PCI-Express [x4], 1 x PCI-Express [x1] and 4 x PCI slots
• Includes Impulse's industry leading APT Solutions - Acoustics, Power and Thermal configurations
• Energy efficient - “80 Plus” Certified Gold Class power supplies used as standard
• Chassis colours available in black, beige and RAL7035 (other colours available on request)
• Configuration services available - select your own combination of storage, memory and expansion
• 3 year back-to-base warranty as standard
System Standard I/O
Chassis
Motherboard
CPU
Chipset
LAN Chipset
System memory
HDD storage
SSD storage
Optical drive
Expansion
Power supply
Operating system
iAMT Version
Audio
System control
LED indicators
SB630-CRM - Intel Core i7/i5/i3 LGA1155 ATX Motherboard
Intel Core i7-2600 3.40GHz Processor
Intel Q67
Intel 82579LM and Intel 82574L
Up to 32GB DDR3-1333MHz DIMM Memory
500GB or 1TB (other capacities available upon request)
40GB or 120GB (other capacities available upon request)
CD/DVD-RW Combo Drive in Black (Bluray Drive optional)
1 x PCI-E [x16] Slot, 1 x PCI-E 2.0 [x8] Slot, 1 x PCI-E [x1] Slot,
4x PCI Slots
650W (default), 550W and 750W (optional)
Win 7 Professional, Win XP for Embedded Systems (optional)
7.0
Realtek ALC886 5.1 HD Audio
1 x Power ON/OFF Switch, 1 x Reset Button
Power On, HDD Active Display
LAN
USB
Serial
1 x VGA DB15 Port
1 x DVI-I Port
2 x 10/100/1000 RJ45 Gigabit
Ethernet Ports
2 x USB2.0 Ports (rear)
6 x USB2.0 Ports (front)
2 x RS-232/422/485 Ports (Rear)
Environmental
Warranty
Operating temp.
Certification 3 year back-to-base warranty
0°C to +60°C
CE, 80 Plus Gold, RoHS
GH-414ATXR - 19" 4U Rack-mount
Heavy duty cold rolled electroplated
steel
Black, Beige or RAL7035
Other colours available on request
2 x 3.5” Bays, 3 x 5.25” Bays
1 x 120mm fan (default) or 2 x 120mm
fans (optional)
2 x front accessible doors with key lock
1 x washable air filter
W483mm x H117mm x D510mm
17.4 kgs Chassis type
Construction
Chassis colour
Drive bays
Cooling
Doors
Filter
Dimensions
Gross weight
4720
1.0 Document created 05 Oct 2012
