Impulse AX61622 - Manual

291 * All specifications and photos are subject to change without notice.
Items
Specifications
Input Output MTBF
PS400-
XP2
PS500-
XP2
RPS460-
HRP
100,000
hours
PS300-
XP2
Watt
100,000
hours
100,000
hours
200,000
hours
Slide Switch
(115V AC /230V AC )
AC 90~264V
(Auto)
AC 90~264V
(Auto)
AC 100~240V
(Auto)
ATX 300W
(PFC)
ATX 400W
(PFC)
ATX 500W
(PFC)
ATX 460W
HRP
(PFC)
+5V @ 30/21.5A
+12V @ 15A
-12V @ 0.8A
+3.3V @ 15/28A
+5VSB @ 2A
-5V @ 0.3A
+5V @ 20A
+3.3V @ 20A
+12V1 @ 16A
+12V2 @ 16A
-12V @ 0.5A
+5VSB @ 2.5A
+5V @ 24A
+3.3V @ 24A
+12V @ 34A
+12V1 @ 17A
+12V2 @ 17A
-12V @ 0.8A
+5VSB @ 2.5A
+5V @ 40A
+12V @ 32A
-5V @ 0.8A
-12V @ 1A
+3.3V @ 30A
+5VSB @ 2A
Backplane Options
Models
Slots per Segment
(ISA/PCI/CPU)
Segment
Power Supply Specifications
6U 20-slot Rackmount Chassis
AX61622
Specifications
Features
6U-high 20-slot rackmount chassis
Supports hot-swap redundant power supply
Internal four 5.25" HDD drive bays
Easy to replace fan filter by hand
Up to 4 systems in a chassis
Dimensions
Standard Color Black
Drive Capacity Exposed 4 x 5.25" HDD drive bay, 2 x 3.5" HDD drive
bay
Cooling 4 x (49 CFM/each) with a removable filter
System Board SBCs
Expansion Interface 20-slot backplane
Operating Temperature 0˚C ~ 45˚C (32˚F ~ 113˚F)
Range
Dimensions
482.6mm (19") (W) x 462mm (18") (D)
x 266mm (10.5") (H)
Weight (net/gross) 17 kg (37.48 lb)/18.3 kg (40.34 lb)
ATX6022/20G
ATX6022/20GP18
ATX6022/20Q 7/12/1
1/18/1
1/3/1
Single
Single
Quad
Ordering Information
AX61622TB/X400 20-slot version, with ATX 400W power supply
AX61622TB/X500 20-slot version, with ATX 500W power supply
AX61622TB/X460R 20-slot version, with ATX 460W redundant
power supply
Top View
Rear View
Front View
Easy to replace
fan filter by hand
Optional hot-swap redundant power supply
Max. 20 slot
backplane
Four 49-CFM
cooling fans
* Specifications and certifications are limited to optional.
** T-Black color
