Impulse AX61460TM - Manual

279 * All specifi cations and photos are subject to change without notice.
Backplane Options
Optional Items
Models
Slots per Segment
(ISA/PCI/CPU)
Segment
Power Supply Specifications
4U 14-slot Rackmount Chassis with Front Accessible I/O
AX61460
Ordering Information
Specifications
Features
Supports ATX motherboard or 14-slot backplane
User-friendly and front-accessible I/O for easy
system maintenance
Supports both single PS/2 and redundant ATX
power supply
Flexible hold-on clamp bar for adjusting different
height of add-on cards
Dimensions
Standard Color Black
Construction Heavy duty cold rolled electroplated steel
Drive Capacity Exposed 1 x slim CD-ROM & 1 x 3.5" FDD;
internal 2 x 3.5" HDD drive bay
Cooling 2 x 9cm ball-bearing fans (51CFM/each)
Front Panel Indicators 1 x power on/off ; 1 x HDD
Front Panel Controls
1 x power on/off , 1 x system reset
Front Panel Connectors 2 x USB
Pre-punched Panel
BP version: 2 x 9-pin DB9
MB version: 1 x 9-pin DB9; 1 x DB25
System Board SBCs or 12" x 9.6" ATX MB or IMB series
Expansion Interface 14-slot backplane
Operating Temperature 0˚C ~ 40˚C (32˚F ~ 104˚F)
Range
Dimensions
483mm (19") (W) x 447mm (17.6") (D)
x 177mm (7") (H)
Weight (net/gross) 14.2 kg (31.3 lb)/15.5 kg (34.18 lb)
Items
Specifications
Input Output MTBF
PS400-
XP2
PS400
-HRP
100,000
hours
100,000
hours
PS301-
XP2
Watt
100,000
hours
AC90~264V
(Auto)
AC90~264V
(Auto)
AC90~264V
(Auto)
ATX400W
HRP
(PFC)
ATX300W
(PFC)
ATX400W
(PFC)
+5V@35A
+12V@28A
[email protected]
[email protected]
+3.3V @ 25A
+5VSB@2A
+5V@30A
+12V@15A
[email protected]
+3.3V@28A
+5VSB@2A
[email protected]
+5V@20A
+12V1@16A
+12V2@16A
[email protected]
+3.3V @ 20A
+5VSB@2A
ATX6022/13L
ATX6022/14G
ATX6022/14D
ATX6022/14GP7
PICMG 1.0
8/4/1
1/12/1
2/4/1
6/7/1
Single
Single
Dual
Single
Models
Slots per Segment
(ISA/PCI/PCIe/CPU)
Segment
FAB100
FAB114
PICMG 1.3
4/4/5/1
0/8/4/1 Single
Single
AX61460TB/X300 14-slot version, with ATX 300W power supply
AX61460TM/X300 MB version, with ATX 300W power supply
Interior view
Rear view
* Specifications and certifications are limited to optional.
** T-Black color; W-Beige color
ATX 500W power supply with PFC
ATX 300W redundant power supply with PFC
Rear view
Front view
3.5" Device
5.25" Slim CD-ROM
9CM FAN
Power
Supply
3.5" HDD* 2EA
427.00
447.00
174.25
86.80
49.80
92.00
92.00
92.00
120.00
482.60
37.70
177.00
101.60
464.60
9CM FAN (Optional)
Left-side view Right-side view TOP view
Front I/O for
easy maintenance
Hot swap redundant
power supply
Flexible hold-on clamp
bar with adjustable clips
to secure add-on card in
different height
