Dimension
Unit: mm
02-12
Passive Backplane Options
P/N
Description
Master Inter-
face
Slots
(PCI/ ISA/ PICMG)
Power
ATX Extend Function
TF-BP-204SI
Wallmount, ISA 4-slot Backplane, 4 ISA, Single Segment, AT
ISA
(0/4/0)
AT
TF-BP-206SI
Wallmount, ISA 6-slot Backplane, 6 ISA, Single Segment, AT/ATX
ISA
(0/6/0)
AT/ATX
BP-208SI
Wallmount, ISA 8-slot Backplane, 8 ISA, Single Segment, AT
ISA
(0/8/0)
AT
TF-BP-214SI-V61
Wallmount, ISA 14-slot Backplane, 14 ISA, Single Segment, AT
ISA
(0/14/0)
AT
HSB-800I
