Specifications

www.lannerinc.com

Ordering Information

Specifications are subject to change without notice

[email protected]

Dimensions (WxHxD)

268x64x190mm (10.55” x 2.52” x 7.60”)

Processor

Intel Atom D525 (1.8GHz)

Chipset

Intel ICH8M

System
Memory

Technology

DDR3 SODIMM x1

Max. Capacity

Up to 4GB

Storage

IDE

CF socket Type I/II x1

SATA

2.5” SSD/HDD drive bay x1

Ethernet Controller

Realtek RTL8111E x2

Graphic Controller

Intel Integrated Graphics Media Accelerator 3150

Audio Controller

Realtek ALC888S

IO

LAN

GbE RJ45 x2

Display

DB15 x1 for VGA
DVI-D x1

Video Grabber

No

Audio

Phone jack x2 for Mic-in / Line-out

Serial I/O

DB9 Male x2 (COM1 & 2)
2x10 pin terminal block connector (COM 3,4,5&6)
COM 1,4,5,6 support RS-232
COM 2,3 support RS-232/422/485

GPS

No

Digital I/O

DB9 Female x1 (for 4 DI / 4 DO (5V TTL)

USB 2.0

Type A x6; Internal x1

Power Input

2-pin terminal block

Expansion

Mini-PCIe x1 (with SIM card reader)
PCI or PCIe Expansion

Others

External: Power-On Button, Power-On Switch, SMA Antenna
Hole x3, Reset
Internal: PS/2 Keyboard & Mouse, +5Vdc output

Power Input

+9~30Vdc with ATX Mode

AC Adapter

75W +19V @ 3.95A

Hardware Monitor

Fintek 81865F
Watchdog Time 1~255 level

OS Support

Linux, XPE/WES2009, XP Pro FES, WS7E, WS7P, Win 7 Pro FES

Certifications

CE, FCC Class A

Compliance

No

Operating
Temperature
Range

With Industrial
Components

-10~55°C / 14~131°F
Passed Extended Operating Temperature Test:
70° C: No Damage after 72-hours full-loading operating
-20° C: Bootable after 24-hours

With Commercial
Components

-5~45°C / 23~113°F

LEC-2110P

Embedded Controller w/ Intel Atom D525, up
to 4GBs of DDR3 memory, VGA/DVI, Audio, 2x
GbE, 2x RS232/422/485, 4x RS232, 6x USB, DIO,
1x mini-PCIe with SIM, 1x PCI expansion

LEC-2110E

Embedded Controller w/ Intel Atom D525, up
to 4GBs of DDR3 memory, VGA/DVI, Audio, 2x
GbE, 2x RS232/422/485, 4x RS232, 6x USB, DIO,
1x mini-PCIe with SIM, 1x PCIe expansion

Standard Accessories

080W1N2201001

SATA SSD / HDD cable w/ power

SE9ESA8740100

Wall Mount

0P0W075190001

75W 19V/3.95A adaptor

04AW20023Z101

Terminal block for remote power on button

04AW20101O101

2 x 10pin terminal block for COM 3,4,5,6

Optional Power Cords

080W240318306

US Power Cord

080W240318305

Schuko (EU) Power Cord

080W240318301

UK Power Cord

080W240318307

China Power Cord

080W240318309

Japan Power Cord

Optional Accessories

PE9ESA8300100

Vesa Mount

0TAWMC8790Z01

3G Module: Sierra MC8790

0TAW0EM770Z01

3G Module: HuaWei EM770W (**MOQ 200)

0TAWE34600Z01

3G Module: Novatel E346 (**MOQ 50)

0TAWQ802XKZ02

Wi-Fi Module: 802.11 b/g/n Mini-PCIe card

0TAWXM100BZ01

Video Decoder: XM100BF HD Video Decoder

Last Updated: 31-Jan-2011
