Model Type 3300MX-TAP 3300MX-TMAP 3300MX-THAP 3300MX-TCAP
Processor PMX-1000 / Voterx86MX+ (933MHz)
Memory Onboard 512MB DDR2/ Onboard 1GB DDR2 (Note 1.)
VGA Integrated Graphics Chip / RCA Jack
Ethernet 10/100 Mbps LAN (RJ-45 connector) Built-in PXE diskless boot function
USB External : 3 ports (2 at the front) Internal : 1 port (reserve for USB Dongle)
Audio Mic in and Line out
GPIO N/A
MIO
SD Slot 1x
SATA (Note 2.) 1x N/A 1x N/A
PS2 N/A
Serial
RS-232(Note 3.) 3x N/A N/A 3x
RS-422 N/A N/A N/A N/A
RS-485 N/A N/A N/A N/A
Power DC +8V ~ +15V
Dimensions 115 x 115 x 35 mm
Weight 500g
Operation Temp. 5 ~ 50 ℃
Model Type EBOX-3310MX-TS4C (TV-In) EBOX-3310MX-TD4C (TV-In)
Processor Vortex86MX+ (933MHz)
Memory Onboard 1GB DDR2 (Note 1.)
VGA Integrated Graphics Chip / D-Sub15-pin
Ethernet 10/100 Mbps LAN (RJ-45 connector) Built-in PXE diskless boot function
USB External : 6 ports (4 at the front; 1 at the back) Internal : 1 port (reserve for USB Dongle)
Audio N/A
GPIO N/A
MIO
SD Slot 1x N/A
SATA (Note 2.) N/A 1x
PS2 N/A
Serial
RS-232(Note 3.) 4x 4x
RS-422 N/A
RS-485 N/A
Power DC +8V ~ +15V
Dimensions 115 x 115 x 35 mm
Weight 500g
Operation Temp 5 ~ 50 ℃
