ROC315B
Intel® Atom™ N455 Fanless Rugged System, 9V to 30V DC-in, Wide Temp. -20 to 70°C
(-40 to 70°C optional)
• Supports Intel® Atom N455 (1.66 GHz)
• 1 x 204 pin SO-DIMM DDR3 800 up to 2 GB
• Supports 2.5" SATA HDD/SSD & CF card
• 5 x COM ports
• Dual GbE LAN ports
• 9V to 30V DC-in
• Wide temperature -20 to 70°C (-40 to 70°C optional)
• Ultra slim design (H: 51.0 mm)
Main Features
Specifi cations
-20°C~+70°C
SUPPORT
System
CPU Type Intel® Atom™ N455 1.66 GHz
Chipset Intel® ICH8M
Memory Type 1 x 204-pin SO-DIMM DDR3 800 MHz up to 2 GB
BIOS AMI® BIOS
Expansion Slot 1 x Mini PCIe slot
Ethernet 2 x RTL8111DL GbE LAN
Storage 1 x 2.5" SATA HDD/SSD drive bay
1 x external CF socket
Front I/O
USB 4
COM 4 x RS232
COM2~4 with 5V/12V selectable
Power Button Yes
Power LED Yes
HDD LED Yes
Audio Mic-in, Line-out
Rear I/O
VGA 1
Ethernet 2 x RJ45
USB 2
COM 1 x RS232/422/485 with 5V/12V selectable
Antenna Reserved two antenna holes
Power Input 9V to 30V DC-in (By terminal block)
CF Socket 1
Mechanical & Environment
Construction Aluminum chassis with fanless design
Power
Requirements 9V to 30V DC-in
Dimension
(W x H x D) 195 x 51 x 230 mm
(7.7" x 2'' x 9'')
Operating Temp. -20 to 70°C (ambient with air fl ow)
Storage Temp. -40 to 80°C
Relative Humidity 10% to 90%, non-condensing
Certifi cations CE, FCC
