Specifications Ordering Information
Dimensions
Safety
Compliance
UL508, UL60950-1
Heavy Industrial CE, including:
EN60950-1, IEC60950-1
EMI
Compliance
FCC Part 18
Heavy Industrial CE, including:
EN61000-6-4, EN61000-3-2, EN61000-3-3
EMS
Compliance
EN50121-4 (Railway application)
Heavy Industrial CE, including:
EN61000-6-2
EN61000-4-2 (ESD standards)
* Contact: +/- 6 KV; criteria B
* Air: +/- 8 KV; criteria B
EN61000-4-3 (radiated RFI standards)
* 10V/m, 80 to 1000 MHz; 80% AM criteria A
EN61000-4-4 (burst standards)
* Signal ports: +/- 2 KV; criteria B
* DC power ports: +/- 2 KV; criteria B
EN61000-4-5 (surge standards)
* Signal ports: +/- 1 KV; line-to-line; criteria B
* DC power ports: +/- 0.5 KV; line-to-earth; criteria B
EN61000-4-6 (induced RFI standards)
* Signal ports: 10 Vrms @ 0.15 ~ 80 MHz; 80% AM
criteria A
* DC power ports: 10 Vrms @ 0.15 ~ 80 MHz; 80% AM
criteria A
EN61000-4-8 (magnetic field standards)
* 30 A/m @ 50, 60 Hz; criteria A
Environmental Test
Compliance
IEC60068-2-6 Fc (vibration resistance)
5 g @ 10 ~ 150 Hz, amplitude 0.35 mm (operation/storage/
transport)
IEC60068-2-27 Ea (shock) 25 g @ 11 ms (half-sine shock
pulse; operation); 50 g @ 11 ms (half-sine shock pulse;
storage/transport)
IEC60068-2-32 Ed (free fall) 1 M (3.281ft)
Standard
rBOX201-4COM-FL
Robust Din-rail fanless embedded system with AMD LX800
processor and 4 isolated COM ports (-40°C ~ +70°C)
Optional
DDR SO-DIMM
512 MB ~ 1 GB (with W.T. memory)
CompactFlash™ 2 GB or above (with W.T. CF)
Wall mount kit
Wireless (3G/GPRS) module for rBOX seriesit
*Specifications and certifications are based on options and may vary.
