Embedded System
1 x QIG
1 x Screw set
2 x Wall mount bracket
1 x Driver CD
1 x 12V DC 60W power adaptor (with ErP and PSE certificates)
1 x Power cord
1 x 2dbi wireless antenna (for wireless model only)
Part No. Description
NANO-PV-D5251-R10 EPIC with Intel® Atom™ D525 1.8GHz, DDR3, VGA/LVDS, Dual GbE, USB 2.0, CF II, audio and SATA II, RoHS
NANO-PV-D4251-R10 EPIC with Intel® Atom™ D425 1.8GHz, DDR3, VGA/LVDS, Dual GbE, USB 2.0, CF II, audio and SATA II, RoHS
NANO-PV-N4551-R10 EPIC with Intel® Atom™ N455 1.66GHz, DDR3, VGA/LVDS, Dual GbE, USB 2.0, CF II, audio and SATA II, RoHS
ECN-581A-R10-D5251
Embedded chassis for NANO-PV-D5251, Support Intel® Atom™ D525 Processor, DDR3 SO-Dimm memory, 12VDC, 60W power adaptor with ERP and PSE
certificates, Reflex Blue C + 8403C, RoHS, w/o MB
ECN-581AW-R10-D5251
Embedded chassis for NANO-PV-D5251, Support Intel® Atom™ D525 Processor, DDR3 SO-Dimm memory, 802.11b/g/n wireless, 12VDC, 60W power adaptor
with ERP and PSE certificates, Reflex Blue C + 8403C, RoHS, w/o MB
NANO-HM551-R10 EPIC SBC supports Socket G1 for Intel® Core™ i7 CPU, VGA/HDMI, Dual PCIe GbE, USB 2.0, Mini PCIe, SATA II and Audio, RoHS
ECN-581A-R10-HM551
Embedded chassis for NANO-HM551, Support Intel® Core i5/ i3/ Celeron® Processor, DDR3 SO-Dimm memory, 12VDC, 60W power adaptor with ERP and
PSE certificates, Reflex Blue C + 8403C, RoHS, w/o MB
ECN-581AW-R10-HM551
Embedded chassis for NANO-HM551, Support Intel® Core i5/ i3/ Celeron® Processor, DDR3 SO-Dimm memory, 802.11b/g/n wireless, 12VDC, 60W power
adaptor with ERP and PSE certificates, Reflex Blue C + 8403C, RoHS, w/o MB
CF-989A-RS-R11 CPU cooler for mobile socket-G (PGA988) up to 55W processor, Copper, 60x60x27.6mm, RoHS
1 x 2.5” SATA HDD space
Note: Above Part No. is for chassis only without MB.
Ordering Information
Dimensions
(Unit: mm)
Packing List
ECN-581A for HM55/D525-2011-V10
