Features
PC
/1
04
Mod
ules
Specifications
9657666600 •
Jumper Cap
17592LNP00 •
Heatsink
Product CD •
PFM-LNP with Cooler •
Packing List
PC/104 Module with Intel® Atom™ N450 Processor
System
Form Factor PC/104
Processor Intel® Atom™ N450 1.66 GHz Processor
System Memory Onboard DDR2 667, Max. 1 GB
Chipset Intel® ICH8M
I/O Chipset SCH3114
Ethernet Intel® 82567V for 10/1000/1000Base-TX x 1
BIOS AMI BIOS – 4 MB Flash
Wake on LAN Yes
Watchdog Timer Generates a time-out system reset
H/W Status Monitoring Supports Power Supply Voltage, Fan Speed and Temperature Monitoring.
Expansion Interface PCI-104, Mini Card
Battery Lithium battery
Power Requirement 12V
Power Consumption
(Typical) Intel® Atom™ N450 1.66GHz, DDR2 667 1 GB
1.3A@+12V
Board Size 3.55" x 3.77" (90mm x 96mm)
Gross Weight 0.35 lb (0.16 Kg)
Operating Temperature 32°F ~ 140°F (0°C ~ 60°C)
Storage Temperature -40°F ~ 176°F (-40°C ~ 80°C)
Operating Humidity 0% ~ 90% relative humidity, non-condensing
MTBF (Hours) 83,000
Display Supports CRT/LCD simultaneous/ dual view displays
Chipset Intel® Atom™ N450 processor integrated
Memory Shared system memory up to 384 MB/ DVMT 4.0
Resolutions
Up to 1400 x 1050 for CRT
Up to 1280 x 768 for LCD
LCD Interface 18-bit single channel LVDS
I/O
Storage SATA 3.0Gb/s x 1, Type 1 CompactFlash™ x 1
Serial Port RS-232 x 3, RS-232/422/485 x 1
Universal Serial Bus USB2.0 x 4
PS/2 Port Keyboard + Mouse x 1
PFM-LNP
Intel® Atom™ N450 1.66 GHz Processor ■ ■
Intel® ICH8M ■ ■
Onboard DDR2 667 Memory, Max. 1 GB ■ ■
Gigabit Ethernet x 1 ■ ■
CRT, 18-bit Single Channel LVDS LCD ■ ■
SATA 3.0Gb/s x 1, CompactFlash™ x 1 ■ ■
USB2.0 x 4, COM x 4 ■ ■
PCI-104, Mini Card Expansion Interfaces ■ ■
+12V Only Operation ■ ■
USB Power SATA
COM
VGA
LVDS
SIM LAN FAN
Front Panel
LAN LED
Keyboard &
Mouse
SATA Power
