04-16
Dimension
Unit: mm
PFM-P13DW2-A10 •
PC/104 Board Power Supply Module with +5V & +12V Output PC/104 Rev. A1.0 WiTAS 2
1701400205 •
COM Cable, Length 20cm
1709100201 •
USB Cable, Length 20cm
1701260201 •
Printer Cable, Length 20cm
1700100201 •
LAN Cable, Length 20cm
1701080150 •
8-pin Front Panel, Length 15cm
1701010150 •
10-pin Front Panel, Length 15cm
Optional Accessories
PFM-535S
Part Number CPU RAM Fan/ Fanless Storage Display LVDS LAN USB RS-232
RS-
232/422/485
Parallel Expansion Slot Power Temp.
PFM-535S-A10 Vortex86SX 300 MHz 256MB Fanless
EIDE x 1,
CompactFlash™ x 1
CRT + TTL 24b, 1CH FE x 2 4 3 1 1 PC/104+ +5V/AT 0°C ~ 60°C
PFM-535S-A10-01 Vortex86SX 300 MHz 256MB Fanless
EIDE x 1,
CompactFlash™ x 1
CRT + TTL 24b, 1CH FE x 1 4 3 1 — PC/104 +5V/AT 0°C ~ 60°C
PFM-535S-A10-02 Vortex86DX 1GHz 256MB Fanless
EIDE x 1,
CompactFlash™ x 1
CRT + TTL 24b, 1CH FE x 2 4 3 1 1 PC/104+ +5V/AT 0°C ~ 60°C
Ordering Information
