Intel Tunnel Creek
E620T
SATA
Connector
CH7317B
TOPCLIFF
EG20T
SDVO
LVDS 24-bit
LVDS
SPI
Flash ROM
SPI
SMSC
SCH3114
LPC Header
LPC
VGA
connector
RGB
USB
2 x USB
TJA1040T
CAN Bus
Connector
SATA 0
CF Slot JMD330
SATA 1 IDE
DIO port
GPIO
PCIe x1
Onboard 1GB
DDR2 RAM
INTEL
82574IT
PCIe x1
RJ45
INTEL
82574IT
PCIe x1
RJ45
Mini PCIe
PCIe x1 Audio
ALC886
HDA
1 x RS232/422/485
(5V/12C selectable)
COM1
3 x RS232
COM2,3,4
12V DC-in
3.5" SBC - OXY5319A
Block Diagram
Packing List Ordering Information
Modules
Model Number Description
OXY5319A-ET 3.5" SBC Intel® Tunnel Creek E620T + Topcliff EG20T
with DDR2 onbord Memory Dual Display by VGA/
LVDS, Dual GbE LAN, 4 x COM, 4 x USB, CAN Bus,
and 12V DC-in
(-20 to 70°C)
OXY5319A-UT 3.5" SBC Intel® Tunnel Creek E620T + Topcliff EG20T
with DDR2 onbord Memory Dual Display by VGA/
LVDS, Dual GbE LAN, 4 x COM, 4 x USB, CAN Bus,
and 12V DC-in
(-40 to 85°C optional)
• OXY5319A 3.5” SBC
• CD (Driver + user's manual)
Cable Kit
Cable kit for OXY5319A
CF Card
Innodisk iCF4000 series
Apacer Industrial CF series
Optional Accessories
