DFI reserves the right to change the specifications at any time prior to the product's release. Changes thereafter will be based on the product's revision.

Please contact your sales representative for the exact revision offered in your area. Refer to the website (www.dfi.com) for the most updated information.

All product names mentioned are trademarks of their respective companies. © September 18, 2013 DFI Inc.

www.dfi.com

Specifications

HD630-H81

ATX

HD630-H81

ATX

• 1 HD630 motherboard

• 1 Serial ATA data cable

• 1 I/O shield

• 1 DVD

• 1 QR (Quick Reference)

Packing List

Optional Items

• USB port cable

• COM port cable

• Serial ATA data cable

• Serial ATA power cable

• I/O shield

• 1 LPC module kit

PROCESSOR

• LGA 1150 socket for:

- 4th Generation Intel

Core

processors (22nm process technology)

: Intel

Core

i3-4330 (3M Cache, 3.5 GHz); 54W

: Intel

Core

i3-4330TE (3M Cache, up to 2.4 GHz); 35W

: Intel

Pentium

G3420 (3M Cache, 3.2 GHz); 54W

: Intel

Pentium

G3320TE (3M Cache, 2.3 GHz); 35W

CHIPSET

• Intel

H81 Express Chipset

SYSTEM MEMORY

• Two 240-pin DDR3/DDR3L DIMM sockets

• Supports DDR3/DDR3L 1333/1600MHz

• Supports dual channel memory interface

• Supports up to 16GB system memory

• DRAM device technologies: 1Gb, 2Gb and 4Gb DDR3 DRAM

technologies are supported for x8 and x16 devices, unbuffered,

non-ECC

EXPANSION SLOTS

• 1 PCIe x16 Gen 2 slot (PCIe 2.0)

• 1 PCIe x4 Gen 2 slot (PCIe 2.0)

- x1 signal

• 1 PCIe x1 Gen 2 slot (PCIe 2.0)

• 4 PCI slots (PCI 2.3)

• 1 Mini PCIe slot

- Supports USB and PCIe signals

- Supports mSATA

- Supports half size and/or full size Mini PCIe card

ONBOARD GRAPHICS FEATURES

• Intel

HD Graphics

• Display ports: HDMI and DVI-I

• DVI-I supports up to 1920x1200 @ 60Hz resolution

• HDMI supports up to 4096x2304 @ 24Hz resolution or 2560x1600 @

60Hz resolution

• VGA display resolution up to 1920x1200 pixels with 24-bit color @

60Hz

• Supports 6 Graphics Execution Units (EUs)

• Intel

Clear Video Technology

• DirectX Video Acceleration (DXVA) support for accelerating video

processing

ONBOARD AUDIO FEATURES

• Realtek ALC886 5.1-channel High Definition Audio

• Audio outputs: Mic-in/Center+Subwoofer, line-in/surround and line

out

• S/PDIF audio interface

ONBOARD LAN FEATURES

• Intel

I210 PCI Express Gigabit Ethernet controller

• Intel

I217LM Gigabit Ethernet Phy

• Integrated 10/100/1000 transceiver

• Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

SERIAL ATA (SATA) INTERFACE

• 2 SATA 3.0 ports with data transfer rate up to 6Gb/s

• 2 SATA 2.0 ports with data transfer rate up to 3Gb/s

• Integrated Advanced Host Controller Interface (AHCI) controller

TRUSTED PLATFORM MODULE (TPM) - optional

• Provides a Trusted PC for secure transactions

• Provides software license protection, enforcement and password protection

REAR PANEL I/O PORTS

• 1 mini-DIN-6 port for PS/2 mouse/keyboard

• 2 DB-9 RS232/422/485 serial ports (RS232 and/or Power)

• 1 HDMI port

• 1 DVI-I port

• 2 RJ45 LAN ports

• 2 USB 3.0/2.0/1.1 ports

• 4 USB 2.0/1.1 ports

• Line-in/Surround, Line out, Mic-in/Center+Subwoofer jacks
I/O CONNECTORS

• 1 connector for 2 external USB 2.0/1.1 ports

• 1 8-bit Digital I/O connector

• 1 Digital I/O power connector

• 1 front audio connector for line-out and mic-in jacks

• 1 S/PDIF connector

• 1 LPC connector

• 1 parallel port

• 4 Serial ATA ports

• 1 24-pin ATX power connector

• 1 8-pin 12V power connector

• 1 chassis intrusion connector

• 1 front panel connector

• 3 fan connectors
BIOS

• AMI BIOS

- 64Mbit SPI BIOS

WATCHDOG TIMER

• Software programmable from 1 to 255 seconds
ENERGY EFFICIENT DESIGN

• Supports ErP Lot6 power saving (optional)

• Supports ACPI

• System Power Management

• Wake-On-Events include:

- Wake-On-PS/2 KB/Mouse

- Wake-On-USB KB/Mouse

- Wake-On-LAN

- RTC timer to power-on the system

• CPU stopped clock control

• AC power failure recovery
DAMAGE FREE INTELLIGENCE

• Monitors CPU/system temperature and overheat alarm

• Monitors VCORE/5V/3.3V/V_DIMM/12V/5VSB voltages and

failure alarm

• Monitors CPU/system fan speed and failure alarm

• Read back capability that displays temperature, voltage

and fan speed
OS SUPPORT

• Windows XP Professional x86 & SP3 (32-bit)

• Windows XP Professional x64 & SP2 (64-bit)

• Windows 7 Ultimate x86 & SP1 (32-bit)

• Windows 7 Ultimate x64 & SP1 (64-bit)

• Windows 8 Enterprise x86 (32-bit)

• Windows 8 Enterprise x64 (64-bit)
TEMPERATURE

• Operating: 0

C to 60

• Storage: -20

C to 85

HUMIDITY

• 5% to 90%
DIMENSIONS

• ATX form factor

• 305mm (12") x 244mm (9.6")

4th Generation Intel

Core

Processors

Model Name

Part Number

Description

HD630-H81D

770-HD6301-000G

4th Generation Intel

Core

processors

Ordering Information
